DMX
PROTOCOL
Channel
Value
0 - 4
5 - 154
155 - 169
1
170 - 229
230 - 239
240 - 249
250 - 255
0 - 1
2 - 122
2
123 - 132
133 - 253
254 - 255
0 - 11
12 - 23
24 - 35
36 - 47
48 - 59
60 - 71
72 - 83
84 - 95
96 - 107
108 - 119
3
120 - 131
132 - 143
144 - 155
156 - 167
168 - 179
180 - 191
192 - 203
204 - 215
216 - 227
228 - 239
240 - 255
4
0 - 255
0 - 1
2 - 122
5
123 - 132
133 - 253
254 - 255
6
0 - 2
3 - 255
See also "1-channel DMX operation" on page 14.
18
Percent
Function
Dimmer, Strobe, Reset
0 - 1
Light off
2 - 60
Dimmer, closed to open
61 - 66
Dimmer full open
67 - 89
Strobe, fast to slow
90 - 93
Stand-alone, music trigger
94 - 97
Stand-alone, auto trigger
98 - 100
Reset
Parabolic Reflector
0 - 1
Stop
1 - 48
CCW rotation, slow to fast
49 - 52
Stop
52 - 99
CW rotation, fast to slow
99 - 100
Stop
Color / Gobo Wheel
0 - 4
Open
5 - 8
Worms
9 - 13
Web
14 - 18
Petals
19 - 23
Spokes
24 - 27
Cone
28 - 32
Maze
33 - 37
Crater
38 - 41
Holes
42 - 46
Cross
47 - 51
Jagged Cross
52 - 55
Atomic
56 - 60
Dot Circle
61 - 65
Nordic
66 - 70
Aim
71 - 74
Pie
75 - 79
Tie
80 - 84
Nova
85 - 88
Triple Beam
89 - 96
Blackout
97 - 100
Random "stand-alone" position w/ music or auto trigger
Mirror Drum Swivel
0 - 100
Left to right (127 = neutral)
Mirror Drum Rotation
0 - 1
Stop
1 - 48
CCW rotation, slow to fast
49 - 52
Stop
52 - 99
CW rotation, fast to slow
99 - 100
Stop
Mirror Pan Speed
0 - 1
Tracking (speed function off)
2 - 100
Fast to slow

DMX protocol
