S P E C I A L S E T T I N G S
DIP-switch pins 1 - 9 are used to select special options in stand-alone and
master/slave mode. To enable these options, pin 10 must be ON.
Pin 11 toggles between 1 and 6 channel DMX control. It must be OFF for
master/slave operation.
Lamp life can be extended by reducing the voltage slightly. Set DIP-switch pin 12
to ON for longer lamp life, or OFF for full output intensity.
Note: the fixture shall be disconnected from AC power when changing DIP-
switch settings. Changes take effect only after the fixture has been turned off.
Important! Pin 10 must be ON to enable special settings on pins 1 - 9.
Pin
Acrobat user manual
Setting
Effect
ON
Music trigger
1
OFF
Automatic trigger
ON
Stand-alone mode on, single or master fixture
2
OFF
Stand-alone mode off / slave fixture
ON
Test and adjustment program for service use
3
OFF
Normal operation
ON
Slow mirror movement (set on master fixture)
4
OFF
Fast mirror movement
5
ON/OFF
No function
ON
Random effect wheel position (set on slave fixture)
6
OFF
Effect wheel position same as master
ON
Inverted effect wheel position (set on slave fixture)
7
OFF
Normal effect wheel position
ON
Inverted tilt (set on slave fixture)
8
OFF
Normal tilt
ON
Inverted pan (set on slave fixture)
9
OFF
Normal pan
ON
Enable special settings with pins 1 - 9
10
OFF
Enable DMX address with pins 1 - 9
ON
1-channel mode on
11
OFF
1-channel mode off
ON
Reduced power / increased lamp life
12
OFF
Full power / maximum intensity
DIP-switch settings
11
