• Programming the 4 telephone numbers* - determining
st nd rd th
the 1 , 2 , 3 and 4
system will report event messages that were defined by
the system installer.
• Setting user codes* - programming a security code for
yourself and additional 7 codes for other system users.
Codes 5 through 8 are "Latchkey" user codes (see Para.
2.9 for additional details).
• Enrolling keyfob transmitters* - teaching the PowerMax+
system to recognize the ID code of each keyfob transmitter (multi-
button, SecureCode type, wireless transmitter), so that the
PowerMax+ can respond to commands transmitted by them.
• Setting voice options* - Enabling or disabling verbal
announcements (prompts).
• Auto arm option* - enabling or disabling automatic
arming (at a predefined time).
• Setting auto arm time - selecting automatic arming
time.
• Using squawk option* - enabling/disabling LOW/MID/HI
squawk (short siren sound) upon arming and disarming. All
the options are applicable for wireless siren. For wired siren,
refer to LOW, MID and HI options as "squawk enable".
• Setting the time and time format* - adjusting the built-
in clock to show the correct time and time format.
• Setting the date and date format* - adjusting the built-
in calendar date and date format.
• Setting the scheduler * - setting schedule for devices
start/stop activation.
* This option can be accessed only if master user code
has been entered.

7.2 Entering the User Settings Menu

Figure 7 describes how to enter the User Settings menu.
Display in disarm state when all
zones are secured ("00:00 or
other digits show present time).
Instruction: click <NEXT> key
Resultant display
Instruction: Enter 4-digit master
user code (default "1111"), or
user code (see note below).
These menu items are displayed
only if "bypass" was enabled by
the installer.
* Menu items that are marked
with an asterisk can be
accessed only if master
user code has been entered.
Figure 7 - Entering User Settings Menu
16
telephone numbers to which the
1
READY 00:00
NEXT
NORMAL MODE
2
NEXT
USER SETTINGS
3
OK
ENTER CODE _ _ _ _
4
[master/ user code]
SET BYPASS
NEXT
SHOW BYPASS
NEXT
RECALL BYPASS
NEXT
(*)
SET PHONE NUMBER
NEXT
(*)
SET USER CODES
NEXT
(*)
ENROLL KEYFOB
NEXT
(*)
SET VOICE OPTION
NEXT
(*)
AUTO ARM OPTION
NEXT
(*)
AUTO ARM TIME
NEXT
(*)
SQUAWK OPTION
NEXT
(*)
SET TIME&FORMAT
NEXT
(*)
SET DATE&FORMAT
NEXT
(*)
SCHEDULER
NEXT
(*)
INSTALLER MODE
NEXT
<OK> TO EXIT
Paragraphs 7.3-7.17 include User Settings instructions,
step-by-step. However, if you want to get an overall view of
the entire User Settings menu, refer to figure 8 - User
Setting flow-chart. You can use the flow chart as your only
guide along the user settings process, instead of going
through the step-by-step instructions.

7.3 Bypassing Zones

(Not to be used in UL- listed systems)
A. General Guidance
You can program the PowerMax+ to exclude (bypass)
selected zones, regardless of whether these zones are
"functional" (undisturbed) or "open" (disturbed). Bypassing
permits free movement of people within certain zones
although the system is armed. It is also used to temporarily
remove from service faulty zones that require repair work.
Fire zones can not be bypassed.
Remember – zone bypassing compromises security!
Zone bypassing must be carried out while the system is in
the disarmed state.
Note: Zones will be bypassed throughout one disarm-arm
period only. Disarming the system after arming will
suspend the entire bypassing scheme, which can be
recalled later, if so desired.
B. Bypassing Procedure
Having entered your user code successfully (see Para.
7.2), the display will read:
S E T B Y P A S S
If at this point you click < SHOW/OK >, the number, state
and name of the first zone will be automatically displayed.
Three states are possible:
• Open: The zone is not secured - you can bypass it if you
do not wish or know how to solve the problem just now.
• Bypassed: The zone is presently bypassed (you
bypassed it before but haven't armed the system yet).
• Functional: If there is nothing wrong with the zone, its
state is described as "Functional".
Let us assume that Zone 1 is "open" and you wish to
bypass it, and the rest of the zones are functional.
Action
Z 0 1 : O P E N
K i t c h e n
< O K > T O B Y P A S S
Z 0 1 : B Y P A S S E D
K i t c h e n
Z 0 2 : F u n c t i o n a l
(If you wish to
check the state of
F r o n t d o o r
the next zone)
S E T B Y P A S S
You may now select any other item on the USER
SETTINGS menu or quit programming by clicking
< AWAY >. When < OK > TO EXIT is displayed - click < OK >.
After end of bypassing operation, BYPASS blinks:
R E A D Y B Y P A S S
Resultant Display
(alternating)
(alternating)
(alternating)
or
N O T R E A D Y B Y P A S S
DE5467U
Sound
☺
