PART IDENTIFICATION CHART

Use the drawings below to identify the small parts needed for assembly. The number in parentheses below each
drawing is the key number of the part, from the PART LIST near the end of this manual. The number following the
key number is the quantity needed for assembly. Note: If a part is not in the hardware kit, check to see if it
has been preassembled. Extra parts may be included.
M4 Washer
M8 Locknut
M6 Washer M8 Washer
M8 Curved
(48)––3 (38)––2
(35)––4
(34)––4
Washer (39)––4
M4 x 16mm M4 x 20mm M6 x 15mm M8 x 15mm
Screw (31)––1 Screw (53)––2 Screw (28)––4 Screw (29)––4
M8 x 145mm Bolt
(30)––2
5
