Follett E7CI100A Installation, Operation And Service Manual

Follett E7CI100A Installation, Operation And Service Manual

Countertop and freestanding ice and water dispenser with chewblet ice machine e7ci100a, e7fs100a
Hide thumbs Also See for E7CI100A:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Installation, Operation and Service Manual
Countertop and Freestanding Ice and Water
®
Dispenser with Chewblet
Ice Machine
E7CI100A, E7FS100A
Installation, Operation and Service Manual
Serial numbers E01087 and above
E7CI100A
E7FS100A
Following installation, please forward this manual
to the appropriate operations person.
801 Church Lane • Easton, PA 18040, USA
Order parts online:
Toll free (877) 612-5086 • +1 (610) 252-7301
www.follettice.com
www.follettice.com
00976738R04

Advertisement

Table of Contents
loading

Related Manuals for Follett E7CI100A

Summary of Contents for Follett E7CI100A

  • Page 1 Countertop and Freestanding Ice and Water ® Dispenser with Chewblet Ice Machine E7CI100A, E7FS100A Installation, Operation and Service Manual Serial numbers E01087 and above E7CI100A E7FS100A Following installation, please forward this manual to the appropriate operations person. 801 Church Lane • Easton, PA 18040, USA Order parts online: Toll free (877) 612-5086 •...

  • Page 2: Table Of Contents

    Base Stand ................38 Dispenser and Ice machine E7CI100A/E7FS100A...

  • Page 3: Welcome

    The following is an explanation of the different model numbers. Model Confi guration Ice Machine Capacity Condenser E7 Series Countertop lbs per day Air-cooled Freestanding Dispenser and Ice machine E7CI100A/E7FS100A...

  • Page 4: Important Safety Information

    45 cm (17.53") 106.5 cm (41.93") Unit Shipping Weight 41 kg (90 lb) 54.4 kg (120 lb) Ambient Information CAUTION! The E7CI100A and E7FS100A are for indoor use only. Maximum* Minimum* Air Temperature † 38 C (100 F) 10 C (50 F) Water Temperature 32.2 C (90 F)

  • Page 5: Water

    Refrigeration WARNING! Do not damage the refrigerant circuit. Refrigerant can cause personal injury and/or damage dispenser. § Refrigerant R134a – 204 grams (7.2 oz.) Heat Rejection § 498 W (1700 BTU/hr) Dispenser and Ice machine E7CI100A/E7FS100A...

  • Page 6: Detailed Drawing

    Freestanding models 37.0 cm (14.55") 37.0 cm (14.55") 44.6 cm 44.6 cm (17.54") (17.54") 20.1 cm 17.1 cm (7.93") (6.72") 60 mm 76 mm (2.37") (2.98") 1/4" MPT water inlet 62.0 cm (24.39") 56.0 cm (22.05") Dispenser and Ice machine E7CI100A/E7FS100A...

  • Page 7: Installation

    Follett recommends installing the water fi lter just prior to initial sanitizing. Valve 5. Connect power supply. 6. Sanitize the dispenser prior to use (see Cleaning and Sanitizing on page 13). 1/4" MPT Dispenser and Ice machine E7CI100A/E7FS100A...

  • Page 8: Freestanding Installation

    2.4 m (8 ft.) power cord with choice of CEE 7/7, AS 3112, or BS 1363 plug. § Water: supply line (with shut-off valve) connects to the dispenser's 1/4" MPT inlet. NOTICE! If installing optional Leg Accessory, complete those steps before proceeding. See page 10 for Leg Accessory instructions. Dispenser and Ice machine E7CI100A/E7FS100A...
  • Page 9 Follett recommends installing the water fi lter just prior to initial sanitizing. Valve Connect power supply. 8. Sanitize the dispenser prior to use (see Cleaning and Sanitizing on page 13). 1/4" MPT Dispenser and Ice machine E7CI100A/E7FS100A...
  • Page 10 2. Lift and remove the top panel, set aside (Fig. 9.1). 3. Remove two screws (Fig. 9.2) and remove left side panel. 4. Install fi lter as shown. Turn fi lter clockwise until it is fully seated (Fig. 9.3). Dispenser and Ice machine E7CI100A/E7FS100A...

  • Page 11: Maintenance/Cleaning Mode

    5. Remove and set aside the front panel (Fig. 11.4) - do not disengage the plug on the back of the User Interface or the tubing at the water dispenser chute (if so equipped). Dispenser and Ice machine E7CI100A/E7FS100A...

  • Page 12: Filter Display Indicator Activation

    No internal filter Internal filter supplied or to display "Fresh Filtered" Not used (OFF position) Not used (OFF position) 15 minute delay 30 minute delay Not used (OFF position) Six-month PM enabled Six-month PM disabled Dispenser and Ice machine E7CI100A/E7FS100A...

  • Page 13: Cleaning And Sanitizing

    8. Place a bucket under the dispense chute and remove cap. Note: Some sanitizing solution will remain and drain out when cap is removed. Reposition cap on bin lid spout. 9. Reinstall front panel, ice dispense chute, and drip tray. 10. Press and hold maintenance/clean switch to exit Maintenance Mode. Dispenser and Ice machine E7CI100A/E7FS100A...

  • Page 14: Service

    12 hours has elapsed or ice or water has dispensed. Making ice Green Gearmotor, compressor, and fan motor energized. Low bin Green Bin switch closed calling for ice. Power on Green Power supplied to unit. Dispenser and Ice machine E7CI100A/E7FS100A...

  • Page 15: Evaporator Disassembly

    User Interface. Lift and remove the top panel, set aside (Fig. 16.5). 8. Remove two screws (Fig. 16.6) and remove left side panel. 9. Remove two screws (Fig. 16.7) and remove right side panel. Dispenser and Ice machine E7CI100A/E7FS100A...
  • Page 16 § Pull gear motor from auger (Fig. 18.3). § Remove main housing insulation (Fig. 18.4). 13. Remove all traces of petro-gel from auger shaft. 14. Remove compression nozzle: Fig. 19 § Loosen hose clamp (Fig. 19.1). § Remove transport tube (Fig. 19.2). Dispenser and Ice machine E7CI100A/E7FS100A...
  • Page 17 17. Remove compression nozzle (Fig. 20.3). 18. Remove main housing: Fig. 21 § Disconnect vent line from T fi tting (Fig. 21.1). 19. Remove three M6x25 socket head allen screws Fig. 22 (Fig. 22.1). 20. Remove main housing (Fig. 22.2). Dispenser and Ice machine E7CI100A/E7FS100A...

  • Page 18: Evaporator Assembly

    5. Install auger (Fig. 24.4). 6. Install main housing: Fig. 25 § Slide main housing onto auger shaft (Fig. 25.1). § Install three M6x25 allen screws (Fig. 25.1). § Connect vent line to T fi tting (Fig. 25.1). Dispenser and Ice machine E7CI100A/E7FS100A...
  • Page 19 Fig. 27 9. Tighten hose clamp (Fig. 27.2). 10. Install gear motor: Fig. 28 § Install main housing insulation (Fig. 28.1). § Slide gear motor onto auger shaft (Fig. 28.2). § Install two M6x90 allen screws (Fig. 28.3). Dispenser and Ice machine E7CI100A/E7FS100A...
  • Page 20 13. Install spacer, ensure that key is captured in slot Fig. 30 (Fig. 30.1) 14. Insert screwdriver into groove of auger shaft and pry Fig. 31 shaft outwards (Fig. 31.1). 15. Insert retainer into groove (Fig. 31.2), ensure that retainer is aligned with hole in spacer. Dispenser and Ice machine E7CI100A/E7FS100A...
  • Page 21 16. Install screw and tighten (Fig. 32.1). Fig. 32 17. Plug in gear motor (Fig. 33). Fig. 33 § BLUE to BLUE § BLACK to BLACK § WHITE to WHITE § Connect ground wire with ground screw. Dispenser and Ice machine E7CI100A/E7FS100A...

  • Page 22: Water Feed Schematic

    Service –––––––––––––––––––––––––––––––––––––––––––––––––– (continued) Water Feed Schematic Evaporator Float Water Chute (optional) Water Solenoid Valve Filter (optional) (optional) Water Solenoid Valve Dispenser and Ice machine E7CI100A/E7FS100A...

  • Page 23: Bin Melt Water/Evaporator Feed/Clean Out System Schematic

    Bin Melt Water/Evaporator Feed/Clean Out System Schematic Storage Bin Dispenser and Ice machine E7CI100A/E7FS100A...

  • Page 24: Vent System Schematic

    Service –––––––––––––––––––––––––––––––––––––––––––––––––– (continued) Vent System Schematic Storage Bin Vent Tube Reservoir Dispenser and Ice machine E7CI100A/E7FS100A...

  • Page 25: Refrigeration Schematic

    Service –––––––––––––––––––––––––––––––––––––––––––––––––– (continued) Refrigeration Schematic CONDENSER FILTER-DRIER CAP TUBE COMPRESSOR EVAPORATOR ACCUMULATOR LOW PRESSURE LIQUID HIGH PRESSURE VAPOR HIGH PRESSURE LIQUID LOW PRESSURE VAPOR Dispenser and Ice machine E7CI100A/E7FS100A...

  • Page 26: Condenser Fan Motor Removal

    Service –––––––––––––––––––––––––––––––––––––––––––––––––– (continued) Condenser Fan Motor Removal Dispenser and Ice machine E7CI100A/E7FS100A...

  • Page 27: User Interface Display Identifi Cation

    Service - 8000 hr Call Follett Technical Service bushing check Group at (877) 612-5086 or +1 (610) 252-7301. The fl ashing wrench indicates that the 8000 hr bushing check is required. Dispenser and Ice machine E7CI100A/E7FS100A...
  • Page 28 Internal leak in dispenser Locate leak and repair - Press reset on control board. Contact Follett if ice machine is leaking. Sleep mode Press either dispense button to return to normal operation. Dispenser and Ice machine E7CI100A/E7FS100A...

  • Page 29: Electrical Wiring Diagram

    Service –––––––––––––––––––––––––––––––––––––––––––––––––– (continued) Electrical Wiring Diagram Dispenser and Ice machine E7CI100A/E7FS100A...

  • Page 30: Parts

    Parts ––––––––––––––––––––––––––––––––––––––––––––––––––––––––––– Exterior Dispenser and Ice machine E7CI100A/E7FS100A...
  • Page 31 Panel, Rear 00968909 Not Shown Packaging for Returns, Dispenser 00957993 Not Shown Drip Tray Drain Kit 00956375 Not Shown Drip Tray Drain Kit with 4" (10.16 cm) legs 00981977 Not Shown Covers, Agion, User Interface 00969030 Dispenser and Ice machine E7CI100A/E7FS100A...

  • Page 32: Interior

    Parts –––––––––––––––––––––––––––––––––––––––––––––––––––– (continued) Interior Dispenser and Ice machine E7CI100A/E7FS100A...
  • Page 33 00968966 Refrigeration, Piping Assy 00958132 Power Input 00968974 Not Shown Cord, Power IEC60320-C13 to BS 1363 00976753 Not Shown Cord, Power IEC60320-C13 to AS 3112 00976761 Not Shown Cord, Power IEC60320-C13 to CEE 7/7 00976779 Dispenser and Ice machine E7CI100A/E7FS100A...

  • Page 34: Bin Assembly

    Parts –––––––––––––––––––––––––––––––––––––––––––––––––––– (continued) Bin Assembly Dispenser and Ice machine E7CI100A/E7FS100A...
  • Page 35 Lid, Bin Assy 00957779 Bin, Assy 00957787 Auger, Dispense 00957795 Motor, Dispense 00968982 Cap and Insulation, Bin 00957936 Not Shown For serial numbers D17619 and below: Bin Cap 00931519 Ice Chute 00927210 Chute Adapter 00926550 Dispenser and Ice machine E7CI100A/E7FS100A...

  • Page 36: Evaporator Assembly

    Parts –––––––––––––––––––––––––––––––––––––––––––––––––––– (continued) Evaporator Assembly Dispenser and Ice machine E7CI100A/E7FS100A...
  • Page 37 Part # Not Shown Water fi lter cartridge, 5 micron 00968107 Not Shown Cleaning and sanitizing kit, single use 00979856 Not Shown SafeClean, case of 24 00132001 Not Shown IMS II sanitizer concentrate, 16 oz 00979674 Dispenser and Ice machine E7CI100A/E7FS100A...

  • Page 38: Base Stand

    Parts –––––––––––––––––––––––––––––––––––––––––––––––––––– (continued) Base Stand Dispenser and Ice machine E7CI100A/E7FS100A...
  • Page 39 Not Shown IMS II sanitizer concentrate, 16 oz 00979674 Not Shown 6" (15.24 cm) Legs for base stand, set of 4 00956318 Not Shown 4" (10.16 cm) Legs for countertop dispenser, set of 4 00956300 Dispenser and Ice machine E7CI100A/E7FS100A...
  • Page 40 Follett Europe Polska Sp. z o.o. 801 Church Lane • Easton, PA 18040, USA Mokry Dwór 26 c • 83-021 Wiślina, Poland Toll free (877) 612-5086 • +1 (610) 252-7301 +48 (58) 785-6140 • Fax +48 (58) 785-6159 www.follettice.com 00976738R04 www.folletteurope.com © Follet Corporation 8/13...
