Chapter
Jumper Settings and
4
Connectors
This chapter tells how to set up
the UTC-520A/B hardware, includ-
ing instructions on setting jump-
ers and connecting peripherals,
switches and indicators. Be sure
to read all the safety precautions
before you begin the installation
procedures.
Sections include:
Jumpers and Connectors
CMOS Clear for External RTC
(J5)
COM Port Interface
VGA Interface
Watchdog Timer Configuration
4
