EasyCoder 4420/4440 Bar Code Label Printer User's Manual
3. Print a few labels to make sure that the label mark sensor is detecting the black
4. Replace the media cover.
5-12
mark on the media.
Platen
roller
Locate the label mark sensor
behind the platen roller near
the inboard edge of the printer.
Use your finger to adjust
the label mark sensor.
Inboard edge
of printer.
The platen roller
is not shown
for clarity only.
d 39
Label mark
sensor
44XXU052.eps
