Fine-Tuning the Top of Form Position

If the label format prints too close to the front or back edge of the label, you can fine-
tune the position with the top of form (TOF) switch. The TOF switch controls the
position of the format forward or backward along the length of the label.
Only use the TOF switch to fine-tune the label format position after you design the
label. Use PrintSet or the IPL top of form command to control the default TOF setting.
For help on using the top of form command, see the PrintSet online help or the IPL
Programming Reference Manual (Part No. 066396).
The printer returns to the default TOF setting when you
•
cycle printer power.
•
lift the printhead.
The TOF switch is a small rocker switch located on the lower outboard plate of the
printer.
Optimizing Printer Performance
5
O
44XXU045.eps
5-7
