Chapter 3 – Using the Web Management Software
Caller ID Configuration
Enter the string RING to the Caller ID list.
●
Click Add to save the string to the Caller ID list.
●
3.
Click Save & Restart to save all the settings and reboot.
Example 3 – Set Up the Ethernet Router to Activate on Matching Caller IDs Only:
1.
On the PPP > PPP Configuration screen, set up the following parameters and click Submit.
PPP General
Make sure that PPP is enabled.
●
Make sure Dial-on-Demand is enabled.
●
Set the Idle Time Out to the number of seconds you desire.
●
Authentication
Your wireless service provider may require you to have a separate PPP username and password. If so,
●
enter them here.
Note:
If a username and password are required, your wireless provider would have given them to you when
you activated your account.
Modem Configuration
Make sure your Dial Number is entered correctly, for HSPA models, the Dial Number is *99***1#
●
2.
On the PPP > Wakeup-on-Call screen, set up the following parameters and click Submit.
Wakeup-on-Call Configuration
Select Enable for Wakeup-on-Call.
●
Set the Time Delay. You can use the 10 second default.
●
Enter the Init Strings, Set Wakeup Init String 1 by entering AT+CLIP=1 for HSPA models only.
●
Caller ID Configuration
Enter a caller's ID that you want added to the Caller ID list.
●
Click Add to save each Caller ID as it is entered to the Caller ID list.
●
3.
Click Save & Restart to save all the settings and reboot.
34
Multi-Tech Systems, Inc. MultiModem rCell User Guide
