Chapter 3 – Using the Web Management Software
Init Strings:
Model
MTCBA-H3-EN3 AT+CNMI=
Caller ID Configuration
Add "Wakeup on Call"
Caller ID:
Caller Acknowledgement Configuration
Acknowledgement String
to Caller:
Note: If the string is not configured, acknowledgement to the caller will not be sent upon successful caller ID
reception.
32
Configure the router initialization string. This initialization string is specific to the
installed integrated cellular modem. Some initialization may be required for the
integrated cellular modem to accept the Wakeup-on-Call feature. Init-num can range
from 1-5. The default is NULL. Refer to the following table for examples of the Init String
depending on model.
Init 1 Init 2
1,1,0,1,0
To add Caller ID to the Wakeup-on-Call function, enter the Caller ID to be allowed to
wakeup the router. Enter 'RING' (all Caps) to wake up on any call. Enter a CID phone
number or an SMS message. The SMS message string must not contain any spaces
between words.
After entering the Caller ID, click Add. The Caller ID displays at the bottom of the
screen. You can enter any number of IDs you desire.
A Caller ID can be edited or deleted using Options, which will be available once a Caller
ID is displayed.
The configured string of (0 to 40 characters) will be sent to the integrated cellular
modem upon receiving a valid caller ID from the WAN. The default is NULL string.
Init 3 Init 4
AT+CLIP= AT+CNM
1 A
Multi-Tech Systems, Inc. MultiModem rCell User Guide
Ack Comment
Ring, for any
number/call to trigger
Wakeup-on-Call.
