Logging Into Web Management Software; Configuring The Router - Multitech MultiModem rCell User Manual

Note: The computer's settings must be in the same subnet range as the router.
The factory default settings for the router are:
IP Address: 192.168.2.1
Subnet Mask: 255.255.255.0
e. Select Use the following DNS server addresses.
f. Enter the IP Address for the Preferred DNS Server and click OK. Example: 205.171.3.65
g. Close the Local Area Properties screen by clicking OK.

Logging into Web Management Software

The router's Web Management software allows you to configure the Ethernet interface. To login:
1.
Verify that the Status LED is blinking to indicate that router is ready.
2.
Open a web browser.
3.
Enter the default Gateway Address, http://192.168.2.1. The Login window displays.
4.
Enter the default User Name and Password and click Login. The default for both is admin. The Web
Management displays.
Note: User name and password are case-sensitive. Change the default password to improve router security.
See Authentication

Configuring the Router

Use Wizard Setup for basic router configuration. To setup additional features and functions, refer to
Web Management Software. In the Web Management Software:
1.
Click Wizard Setup.
Multi-Tech Systems, Inc. MultiModem rCell User Guide
for more information.
Chapter 2 – Installation
Chapter 3,
15
