SPECIFICATIONS

D General
• Frequency coverage :
Receive
Transmit
• Type of emission
AUS versions
Other versions
• No. of memory Ch. : 500 channels (maximum)
• Usable temp. range : –30˚C to +60˚C;
• Frequency stability : ±0.3 ppm (–30˚C to +60˚C;
• Power supply
AUS versions
Other versions
• Current drain
Transmit
Receive
• Dimensions
Main/Front package 62(H)×174(W)×259(D) mm
• Weight
Main/Front package 3.8 kg, 8.4 lb
61
All stated specifications are typical and subject to change without notice or obligation.
0.5–29.9999 MHz
1.6–29.9999 MHz
:
J3E (USB), A3E (AM) RX only
J3E (USB/LSB), A3E (AM)
A1A (CW), F1B (FSK),
J2B (D1, D2, D3)
–22°F to +140°F
–22°F to +140°F)
: 13.8 V DC (negative ground)
10.8–15.6 V DC
11.73–15.87 V DC
:
Less than 28 A
(at maximum power)
Less than 3.0 A
(at maximum audio)
: (projections are not included)
2.4(H)×6.9(W)×10.2(D) in
: (approximately)
D Transmitter
• Output power : (typical)
AUS versions
J3E HIGH 100 W p-p
MID
LOW
Other versions
J3E/A1A HIGH 125 W p-p
MID
LOW
A3E HIGH 30 W Carrier
MID
LOW
F1B/J2B HIGH 75 W p-p
MID
LOW
• Spurious emission :
USA versions 64 dB
below peak output power
Other versions 64 dB (typical)
below peak output power
• Carrier suppression : 50 dB
below peak output power
• Unwanted sideband suppression :
400 Hz 55 dB
below peak output power
1 kHz 65 dB
below peak output power
D Receiver
• Sensitivity :
J3E (Pre Amp ON)
(0.5–1.5999 MHz) 14 dBµV (10 dB S/N)
(1.6–29.9999 MHz) –14 dBµV (10 dB S/N)
A3E
(0.5–1.5999 MHz) 22 dBµV (10 dB S/N)
(1.6–29.9999 MHz) 6 dBµV (10 dB S/N)
• Spurious response rejection ratio:
More than 70 dB
• AF output power : (at 13.8 V DC)
More than 4.0 W at 10%
distortion with a 4 Ω load
• Clarifier range : ±200 Hz
50 W p-p
10 W p-p
50 W p-p
10 W p-p
12.5 W Carrier
3 W Carrier
50 W p-p
10 W p-p
