6
CONNECTION AND INSTALLATION

■ Connector information for AD-119

GPIO Pin Pin name
9 15
1 8
GPS Pin Pin name
6 9
1 5
59
1 13.8V 13.8 V output for Antenna tuner.
2 SCAN Output for Antenna tuner control signal.
3 KEY Key signal input.
4 RL1 Goes to ground when transmitting.
5 TUM4 Stepping motor control signal output for AT230.
6 TUM3 Stepping motor control signal output for AT230.
7 TUM2 Stepping motor control signal output for AT230.
8 TUM1 Stepping motor control signal output for AT230.
9 NC No connection.
10 NC No connection.
11 START Start/bypass signal output.
12 CWKEY CW and FSK keying input.
13 ALC ALC voltage input.
14 GND Connect to ground.
15 TUMB Band control signal output for AT230.
1 3V DC 3 V output (200 mA maximum ).
2 RXD Input terminal for receive data.
3 – —
4 NC No connection.
5 GND Connect to ground.
6 – —
7 – —
8 – —
9 ALCV —
Description
Description
Specification
–0.5 to 0.8 V while tuning
Input level : Less than 0.6 V for
transmit
Control voltage : –4 to 0 V
Input impedance : More than 10 kΩ
