Hardware Installation
2-2 INSTALLATION GUIDE
We will now begin the installation of the Motherboard. Please follow the
step-by-step procedure designed to lead you to a complete and correct
installation.
Warning: Turn off the power to the Motherboard, system
chassis, and peripheral devices before performing any work on
the Motherboard or system.
BEGIN THE INSTALLATION
Step 1 Install the CPU
Your SY-7VBA133U motherboard comes with a CPU retention set kit.
The retention set is used to hold the processor attached to the Socket 370
CPU connector on the motherboard.
CPU Mount Procedure:
processor that you have purchased separately, follow these instructions.
1.
Lift the socket handle up to a vertical position.
To mount the Pentium®, Celeron
10
SY-7VBA133U
TM
, Tualatin
