Hardware Installation
GND
(2) Chassis Cooling Fan
Some chassis also feature a cooling fan. This Motherboard features a
CHAFAN connector to provide 12V power to the chassis fan. Connect the
cable from the chassis fan to the CHAFAN 3-pin connector. Install
according to the following pin assignment:
Note: CPUFAN must be installed for this Motherboard, CHAFAN is
optional.
CPU Cooling Fan
CPUFAN Pin Assignment
1
2
12V
Chassis Cooling Fan
CHAFAN Pin Assignment
3
2
1
3
SENSOR
SENSOR
12V
GND
24
SY-7VBA133U
