Hardware Installation
1
1
4.
Replace the screw to secure the slot bracket of the expansion card.
5.
Install related driver from the operating system.
Step 4 Connect cables, case wires, and power supply
A. IDE Device Installation (HDD, CD-ROM)
This Motherboard offers two primary and secondary IDE device
connectors (IDE1, IDE2). It can support up to four high-speed Ultra DMA
33/66/100HDD or CD-ROM.
SDRAM
SDRAM
IDE 1
Primary
IDE
14
SY-7VBA133U
84
84
Pin -1
IDE 2
Secondary
IDE
