BIOS Setup Utility

3-5.6 Onboard Parallel Ports

Onboard Parallel
Ports
Onboard Parallel
Port
Onboard Parallel
Port Mode
If [Parallel Port Mode] is set to [ECP] mode
ECP Mode Use
DMA
If [Parallel Port Mode] is set to [EPP] mode
Parallel Port EPP
TYPE

3-5.7 Onboard Legacy Audio

This field controls the onboard legacy audio.
Onboard
Legacy Audio
Sound Blaster
SB I/O Base
Address
SB IRQ Select
SB DMA Select
Setting
Disabled
378/IRQ7
3BC/IRQ7
278/IRQ5
Normal
EPP
ECP
ECP+EPP
3
1
EPP 1.9
EPP 1.7
Setting Description
Disabled Set this item to Enabled if using
software (like DOS games) that needs
Enabled
a 'legacy' audio device.
Disabled Set this item to enabled if your
on-board audio-chip is sound Blaster
Enabled
compatible.
220H Select the base address for your
sound Blaster (SB) compatible Audio
IC.
IRQ 5 Select the IRQ your SB Audio IC
uses.
DMA1 Select the DMA channel your SB
Audio IC uses.
Description
Choose the printer I/O
address.
The mode depends on your
external device that
connects to this port.
Choose DMA3
Choose DMA1
Select EPP port type 1.9
Select EPP port type 1.7
51
SY-7VBA133U
Note
Default
Default
Default
Default
Note
Default
Default
Default
Default
Default
