Hardware flow control is not required for this unit. In the rare case where a
controller requires hardware flow control, short pin 1 to 7 and 8, and pin 4
to 6 on the controller side.
Method B
a straight (flat) cable to the null-modem adapter, and connect the null-
modem adapter to the RS-232 9-pin D-sub port on the PC. The straight
cable usually contains all nine wires for a full connection of the D-sub
connector. Because the null-modem adapter (which already includes the
flow control jumpering described in Method A above) only requires pins 2,
3 and 5 to be connected, you are free to decide whether to connect only
these 3 pins or all 9 pins.

Figure 4: Straight Cable RS-232 Connection with a Null-Modem Adapter

5.3

Setting the DIP-Switches

Configure the 7408 unit by setting the DIP-switches, as
DIPS Function
1 PROGRAM
2 VBI
3 PEDESTAL
2
4 4XOS
5 NTSC
6 PAL
7 AUTO
8 COMPONENT
1 NTSC offsets the black level within the active video signal by 7.5 IRE when selected
2 4xOS is 4 x Oversample
3 When this method is used, the noise figure is improved
Using Your 7408 SDI to Analog Converter
(Figure 4)—Connect the RS-232 9-pin D-sub port on the unit via

Table 2: Setting the DIP-switches

ON for upgrading firmware; otherwise OFF
ON to enable Vertical Interval Blanking; OFF to disable
1
ON for pedestal (7.5 IRE offset selection for NTSC); OFF for no pedestal
ON to enable oversampling
ON for NTSC 3.58 (see
ON for PAL (see Table
ON for multi-standard; OFF for user selected (fixed) standard (see
ON for component video; OFF for composite video and/or s-video
Description
3
; OFF to disable oversampling
Table 3)
3)
Table 2 defines:
Table 3)
7
