USER MANUAL
MODEL:
KDS-SW2-EN7
P/N: 2900-301561 Rev 1
4K AVoIP Encoder
www.kramerAV.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the KDS-SW2-EN7 and is the answer not in the manual?

Questions and answers

Related Manuals for Kramer KDS-SW2-EN7

Summary of Contents for Kramer KDS-SW2-EN7

  • Page 1 USER MANUAL MODEL: KDS-SW2-EN7 4K AVoIP Encoder P/N: 2900-301561 Rev 1 www.kramerAV.com...

  • Page 2: Table Of Contents

    Defining KDS-SW2-EN7 Mounting KDS-SW2-EN7 Connecting KDS-SW2-EN7 and KDS-DEC7 Connecting the Audio Input/Output Understanding LED Functionality Connecting to KDS-SW2-EN7 via RS-232 Operating and Controlling KDS-SW2-EN7 Configuring the Network Switch Using Menu Navigation Buttons Operating via Ethernet Using KDS-SW2-EN7 Embedded Web Pages...

  • Page 3: Introduction

    Kramer Electronics Ltd. Introduction Welcome to Kramer Electronics! Since 1981, Kramer Electronics has been providing a world of unique, creative, and affordable solutions to the vast range of problems that confront the video, audio, presentation, and broadcasting professional on a daily basis. In recent years, we...

  • Page 4: Overview

    European Advanced Recycling Network (EARN) and will cover any costs of treatment, recycling and recovery of waste Kramer Electronics branded equipment on arrival at the EARN facility. For details of Kramer’s recycling arrangements in your particular country go to our recycling pages at www.kramerav.com/il/quality/environment.

  • Page 5: Typical Applications

    • Selectable Inputs – 1 HDMI and 1 USB-C input. • Analog/embedded audio inputs and outputs. • Plug-and-play with Netgear M4250 AVoIP switches, Kramer Control, KDS-USB2, etc. Typical Applications KDS-SW2-EN7 is ideal for the following typical applications: • Real-time essential installations such as command and control rooms.

  • Page 6: Defining Kds-Sw2-En7

    Connect to an HDMI acceptor. USB-C IN Port Connect to a USB-C source. When powered by a Kramer 24V power supply (optional), charges sources (that support USB Power Delivery 2.0) up to 60W. LCD Display Use for device configuration such as unique channel/AV stream setting on encoder and channel tuning on decoder.
  • Page 7 USB Type A Charging Connect to USB devices, for example, to a speakerphone and Ports (1 and 2) webcam. HOST USB Type B Port Connect to a USB host. HDMI OUT Connector Connect to loop the signal. KDS-SW2-EN7 – Defining KDS-SW2-EN7...

  • Page 8: Mounting Kds-Sw2-En7

    Kramer Electronics Ltd. Mounting KDS-SW2-EN7 This section provides instructions for mounting KDS-SW2-EN7. Before installing, verify that the environment is within the recommended range: • Operation temperature – 0 to 40C (32 to 104F). • Storage temperature – -40 to +70C (-40 to +158F).

  • Page 9: Connecting Kds-Sw2-En7 And Kds-Dec7

    Always switch off the power to each device before connecting it to your KDS-SW2-EN7 KDS-DEC7. After connecting your devices, connect their power and then switch on the power to each device. Figure 2: Connecting the KDS-SW2-EN7 and KDS-DEC7 To connect KDS-SW2-EN7 as illustrated in the example in Figure 1.

  • Page 10: Connecting The Audio Input/Output

    Kramer Electronics Ltd. 7. Connect the USB ports: ▪ On KDS-SW2-EN7, connect the two USB Type A ports (for example, a webcam and a speakerphone). ▪ On KDS-DEC7, connect a mouse and a keyboard to the two USB type A ports.

  • Page 11: Understanding Led Functionality

    Pin 2 to the TX pin on the KDS-SW2-EN7 RS-232 terminal block • Pin 3 to the RX pin on the KDS-SW2-EN7 RS-232 terminal block • Pin 5 to the G pin on the KDS-SW2-EN7 RS-232 terminal block KDS-SW2-EN7 – Connecting KDS-SW2-EN7 and KDS-DEC7...

  • Page 12: Operating And Controlling Kds-Sw2-En7

    Up arrow – to move to the previous configuration parameter. • Left arrow – to return to the previous menu. • Right arrow – to go to the next menu. • Enter button – accept and save the change. • Defining device settings. KDS-SW2-EN7 – Operating and Controlling KDS-SW2-EN7...
  • Page 13 1. Press the left or right arrows to access the device status menu. 2. Press the up or down arrows to select the input: ▪ HDMI IN ▪ USB-C IN Input signal is selected. KDS-SW2-EN7 – Operating and Controlling KDS-SW2-EN7...
  • Page 14 2. Press the up or down arrows to set a first digit (0 to 9). 3. Press left and right arrows to add another digit (0 to 9). 4. Press Enter to accept channel number. Channel number for this device is defined. KDS-SW2-EN7 – Operating and Controlling KDS-SW2-EN7...

  • Page 15: Operating Via Ethernet

    You can set the channel number via the LCD screen menu or the embedded web pages. To set the channel number for KDS-SW2-EN7, via LCD screen menu: 1. Connect the device to the 24V DC power adapter and connect the adapter to the mains electricity.
  • Page 16 You can connect the Ethernet port of KDS-SW2-EN7 directly to the Ethernet port on your PC using a crossover cable with RJ-45 connectors. This type of connection is recommended for identifying KDS-SW2-EN7 with the factory configured default IP address. KDS-SW2-EN7 – Operating and Controlling KDS-SW2-EN7...
  • Page 17 4. Highlight either Internet Protocol Version 6 (TCP/IPv6) or Internet Protocol Version 4 (TCP/IPv4) depending on the requirements of your IT system. 5. Click Properties. The Internet Protocol Properties window relevant to your IT system appears as shown in Figure 8 Figure KDS-SW2-EN7 – Operating and Controlling KDS-SW2-EN7...
  • Page 18 6. Select Use the following IP Address for static IP addressing and fill in the details as shown in Figure For TCP/IPv4 you can use any IP address in the range 192.168.1.1 to 192.168.1.255 (excluding 192.168.1.39) that is provided by your IT department. KDS-SW2-EN7 – Operating and Controlling KDS-SW2-EN7...
  • Page 19 You can connect the Ethernet port of KDS-SW2-EN7 to the Ethernet port on a network hub or using a straight-through cable with RJ-45 connectors. Configuring Ethernet Port You can set the Ethernet parameters via the embedded web pages. KDS-SW2-EN7 – Operating and Controlling KDS-SW2-EN7...

  • Page 20: Using Kds-Sw2-En7 Embedded Web Pages

    41. • Viewing KDS-SW2-EN7 Status on page 44. • Viewing KDS-SW2-EN7 Connections Status on page 45. • Viewing KDS-SW2-EN7 Advanced Status on page 46. • Viewing the About Page on page 47. KDS-SW2-EN7 – Using KDS-SW2-EN7 Embedded Web Pages...
  • Page 21 3. Enter the Username and Password (Admin/Admin, by default). KDS-SW2-EN7 page appears. Figure 12: Controller Application Page with Navigation List on Left 4. Click the tabs on the left side of the screen to access the relevant web page. KDS-SW2-EN7 – Using KDS-SW2-EN7 Embedded Web Pages...

  • Page 22: Defining Av Routing Parameters

    When the selected video source is disconnected, the device switches to the other (lower priority) video source automatically. • Manual – The input is selected manually. KDS-SW2-EN7 – Using KDS-SW2-EN7 Embedded Web Pages...
  • Page 23 After changing the switching mode, if you need to reboot the device, wait at least 30 seconds before doing so. Switching mode settings will be lost if device is rebooted within 30 seconds of the change. Auto Switching mode is set. KDS-SW2-EN7 – Using KDS-SW2-EN7 Embedded Web Pages...

  • Page 24: Defining Signal Loss Timeouts

    Signal Loss Switching Manual Override Delay – From when KDS-SW2-EN7 detects a signal loss on manual override to when it switches to a different input (default 10). 3. Click SAVE. Signal loss timeouts are defined. KDS-SW2-EN7 – Using KDS-SW2-EN7 Embedded Web Pages...

  • Page 25: Defining Hdmi Input Settings

    When turning the HDCP off on an input, that non-HDCP input source can be routed to the output (for example, for in Apple devices). ▪ Image Preview: view the output video streaming preview. KDS-SW2-EN7 – Using KDS-SW2-EN7 Embedded Web Pages...
  • Page 26 Maximum Video Frame Rate (%): use the slider to configure the maximum frame rate in proportion. 100% (default) means zero compression on the frame rate. 3. Click SAVE. HDMI input settings are defined. KDS-SW2-EN7 – Using KDS-SW2-EN7 Embedded Web Pages...

  • Page 27: Defining Audio Settings

    If IN is selected, the analog audio port is set as an input and KDS-SW2-EN7 includes 2 optional audio sources. If OUT is selected, the analog audio port is set as an output and KDS-SW2-EN7 includes only the HDMI audio source. KDS-SW2-EN7 – Using KDS-SW2-EN7 Embedded Web Pages...
  • Page 28 For example, when in the Last Connected or Priority modes, the currently selected analog audio signal is lost (either becomes silent or is unplugged), the HDMI audio source is automatically selected. 6. Click SAVE. Audio settings are defined. KDS-SW2-EN7 – Using KDS-SW2-EN7 Embedded Web Pages...

  • Page 29: Managing Edid

    Figure 17: AV Settings Page – EDID Management Tab 3. Set EDID Lock: ▪ Click ON, to lock to the last acquired EDID. ▪ Click OFF, to unlock and acquire a new EDID. KDS-SW2-EN7 – Using KDS-SW2-EN7 Embedded Web Pages...

  • Page 30: General Device Settings

    20), view the device model, H/W release version, serial number and MAC address. The DNS name on Windows OS must be within 10 characters in length and cannot include numbers only. KDS-SW2-EN7 – Using KDS-SW2-EN7 Embedded Web Pages...
  • Page 31 30. • Importing/Exporting Device Settings on page 31. • Locating the Device on page 31. • Managing the Firmware Version on page 31. • Restarting or Resetting the Device on page 31. KDS-SW2-EN7 – Using KDS-SW2-EN7 Embedded Web Pages...
  • Page 32 Click Off, to unlock the front panel buttons and enable device control from the front panel via the LCD screen and the navigation buttons(see Using Menu Navigation Buttons on page 10). Front panel buttons are locked/unlocked. KDS-SW2-EN7 – Using KDS-SW2-EN7 Embedded Web Pages...
  • Page 33 Upgrading Firmware on page 53. Click ROLLBACK to update to the previous FW version. Restarting or Resetting the Device Click RESTART to reboot the device and click RESET to restore device factory default settings. KDS-SW2-EN7 – Using KDS-SW2-EN7 Embedded Web Pages...

  • Page 34: Kds-Sw2-En7 Network Settings

    DHCP mode – Set DHCP to On (default) or Off. ▪ IP Address – When DHCP mode is set to Off, the device uses a static IP address. This requires entering mask and gateway addresses. ▪ Mask Address – Enter subnet mask. KDS-SW2-EN7 – Using KDS-SW2-EN7 Embedded Web Pages...
  • Page 35 1. In the Navigation pane, Select Device Settings. The General tab in the Device Settings page appears (see Figure 18). 2. Select the Network tab. The Network tab opens (see Figure 19). 3. Define TCP (default, 5000) and UDP (default, 50000) ports. TCP/UDP ports are defined. KDS-SW2-EN7 – Using KDS-SW2-EN7 Embedded Web Pages...

  • Page 36: Defining Kds-Sw2-En7 Time And Date

    Network fields are enabled. 4. Type in server information: ▪ Enter the server address. ▪ Set daily sync hour. 5. Click SAVE. The devices date and time are synchronized to the server address entered. KDS-SW2-EN7 – Using KDS-SW2-EN7 Embedded Web Pages...

  • Page 37: Setting Kds-Sw2-En7 Security

    1. In the Navigation pane, click Device Settings. The General tab in the Device Settings page appears (see Figure 18). 2. Select Security tab. The Security tab appears. Figure 21: Device Settings Page – Security Tab KDS-SW2-EN7 – Using KDS-SW2-EN7 Embedded Web Pages...
  • Page 38 PEAP-MSCHAP V2 – To use this authentication method, enter a Username (up to 24 alphanumeric characters, including “_” and “-“ characters within the username) and Password (up to 24 ASCII characters): Figure 23: Security Tab – EAP-MSCHAP V2 Authentication KDS-SW2-EN7 – Using KDS-SW2-EN7 Embedded Web Pages...
  • Page 39 (assigned by IT administrator). Set Server Certificate On. Figure 24: EAP-TLS – Certificates and Password 5. Click APPLY. Security is configured. KDS-SW2-EN7 – Using KDS-SW2-EN7 Embedded Web Pages...

  • Page 40: Defining Kds-Sw2-En7 User Access

    Figure 25: Device Settings Page – Users Tab 3. Click On next to Security Status to enable web page authentication (Off by default). The following message appears. Figure 26: Security Tab – Security Status KDS-SW2-EN7 – Using KDS-SW2-EN7 Embedded Web Pages...
  • Page 41 3. Click Off next to Security Status to enable web page authentication. The following message appears. Figure 28: Security Tab – Security Status 4. Enter the current password. 5. Click PROCEED. Security is disabled. KDS-SW2-EN7 – Using KDS-SW2-EN7 Embedded Web Pages...
  • Page 42 8 to 24 characters long. 6. Next to Confirm Password, enter the new password again. 7. Click CHANGE. Password has changed. KDS-SW2-EN7 – Using KDS-SW2-EN7 Embedded Web Pages...

  • Page 43: Defining Kds-Sw2-En7 Gateway Settings

    3. Select the HDMI port from the drop-down list to which CEC commands are sent: ▪ HDMI Input (HDMI IN). ▪ HDMI Loop Through (HDMI OUT). 4. Enter the CEC command. Use hex format for the CEC command, up to 32 hex digits. 5. Click SEND. KDS-SW2-EN7 – Using KDS-SW2-EN7 Embedded Web Pages...
  • Page 44 5. Enter the Data Bits: 5, 6, 7 or 8 (default). 6. Enter Parity: None (default), Odd or Even. 7. Enter Stop Bits: 1 (default) or 2. 8. Click SAVE. RS-232 Gateway is configured. KDS-SW2-EN7 – Using KDS-SW2-EN7 Embedded Web Pages...
  • Page 45 IN – Configure the IR port as an input port that is connected to an IR receiver cable. ▪ OUT – Configure the IR port as an output port that is connected to an IR emitter cable. IR Gateway is configured. KDS-SW2-EN7 – Using KDS-SW2-EN7 Embedded Web Pages...

  • Page 46: Viewing Kds-Sw2-En7 Status

    5. View HDMI OUT and LAN output status: ▪ On, when an output is transmitting a signal (green indication). ▪ Off, when an output has no signal output (gray indication). Device status is viewed. KDS-SW2-EN7 – Using KDS-SW2-EN7 Embedded Web Pages...

  • Page 47: Viewing Kds-Sw2-En7 Connections Status

    33). 2. Select the Connections tab. Figure 34: Diagnostics – Status Tab 3. View the Connections status, including protocol type, client IP address and port, and the device port. Connections’ status is viewed. KDS-SW2-EN7 – Using KDS-SW2-EN7 Embedded Web Pages...

  • Page 48: Viewing Kds-Sw2-En7 Advanced Status

    4. Click VIEW to view the system log, if required. 5. Click EXPORT to export the system log (.txt) to the local PC. 6. View the sent and received gateway messages. System log and counters are viewed. KDS-SW2-EN7 – Using KDS-SW2-EN7 Embedded Web Pages...

  • Page 49: Viewing The About Page

    Kramer Electronics Ltd. Viewing the About Page View the web page hardware release, firmware version and Kramer Electronics Ltd details in the About page. Figure 36: About Page KDS-SW2-EN7 – Using KDS-SW2-EN7 Embedded Web Pages...

  • Page 50: Kvm Roaming, Osd Menu And Fast Switching

    4. Make sure that the PC sub Network is the same as the system devices. Devices are set. Perform the following actions: • Configuring KVM Roaming on page 49. • Fast switching configuration on page 52. KDS-SW2-EN7 – KVM Roaming, OSD menu and Fast Switching...

  • Page 51: Configuring Kvm Roaming

    1. Access the encoder and decoder web pages. 2. For each encoder, in the AV Routing page, select the input, set a unique Channel ID and name. Figure 38: KDS-SW2-EN7 Setting Channel ID and Name KDS-SW2-EN7 – KVM Roaming, OSD menu and Fast Switching...
  • Page 52 4. For the Decoder that has the keyboard and mouse connected, open the Main>KVM Combiner page. Figure 40: Defining the Master Decoder for KVM Roaming 5. Set the Decoder as master. The decoder configuration setup appears. KDS-SW2-EN7 – KVM Roaming, OSD menu and Fast Switching...
  • Page 53 The MAC address is automatically entered. Figure 42: Setting Master MAC Address 8. Manually enter the other (slave) decoder MAC addresses according to the physical setup. 9. Click Slave. KVM Roaming is configured. KDS-SW2-EN7 – KVM Roaming, OSD menu and Fast Switching...

  • Page 54: Fast Switching Configuration

    2. For each encoder, in the AV Routing page, set a unique Channel ID and name. Figure 43: Setting Channel ID and Name on the KDS-SW2-EN7 Devices 3. Make sure that all the encoders in the system share the same settings. For example, to...

  • Page 55: Upgrading Firmware

    Upgrade the firmware, view the date of the last upgrade, or rollback to the previous firmware revision in case of a problem. Click ROLLBACK to update to the previous FW version. If the device firmware version is lower than 0.6.3, contact Kramer tech support team at support@kramerav.com or go to our Web site at k.kramerav.com/support/downloads.asp.

  • Page 56: Technical Specifications

    (7.5" x 5.7" x 1.1") Shipping Dimensions (W, D, H) 31cm x 18cm x 7.6cm (12.2" x 7.09" x 2.99") Net Weight 0.67kg (1.4lbs) approx. Shipping Weight 0.93akg (2lbs) approx. Specifications are subject to change without notice at www.kramerav.com KDS-SW2-EN7 – Technical Specifications...

  • Page 57: Default Communication Parameters

    Red: (0.640, 0.330) Green: (0.300, 0.600) Blue: (0.150, 0.060) White: (0.313, 0.329) Established Timings I 640 x 480 @ 60Hz 800 x 600 @ 60Hz Established Timings II 1024 x 768 @ 60Hz Manufacturer's Timings: None KDS-SW2-EN7 – Technical Specifications...
  • Page 58 SVD #007: (95) 3840x2160p @ 30 Hz 16:9 SVD #008: (94) 3840x2160p @ 25 Hz 16:9 SVD #009: (93) 3840x2160p @ 24 Hz 16:9 SVD #010: (100) 4096x2160p @ 30 Hz 256:135 SVD #011: (99) 4096x2160p @ 25 Hz 256:135 KDS-SW2-EN7 – Technical Specifications...
  • Page 59 HSync Delay: 70 HSync Width: 143 VSync Delay: 3 VSync Width: 3 Image size: 89 mm x 50 mm Border: 0 pixels x 0 lines Stereo mode: Normal display, no stereo Sync: Digital Separate, VSYNC+, HSYNC+ KDS-SW2-EN7 – Technical Specifications...

  • Page 60: Default Parameters

    CEC Gateway Enable CEC Gateway HDMI Port HDMI Input RS232 Gateway Enable RS232 Port 5001 RS232 Baud rate 115200 RS232 Data Bits Parity None Stop Bits IR Gateway Enable IR Direction IN/OUT Diagnostics Advanced Active Syslog KDS-SW2-EN7 – Technical Specifications...

  • Page 61: Protocol 3000

    Parameters attributes – Parameters may contain multiple attributes. Attributes are indicated with pointy brackets (<…>) and must be separated by a period (.). The command framing varies according to how you interface with the KDS-SW2-EN7. The following figure displays how the # command is framed using terminal communication software (such as Hercules): KDS-SW2-EN7 –...

  • Page 62: Protocol 3000 Commands

    – Keep alive timeout in seconds (1 to 3600) com_id – Machine dependent COM- Remove a #COM-ROUTE-REMOVE ~nn@COM-ROUTE-REMOVE Remove a communication ROUTE- communication route com_id<CR> com_id<CR><LF> route tunnel connection: REMOVE tunnel connection. #COM-ROUTE-REMOVE 1<CR> KDS-SW2-EN7 – Protocol 3000...
  • Page 63 #FACTORY<CR> NOTE: This command deletes all user data from the device. The deletion can take some time. Your device may require powering off and powering on for the changes to take effect. KDS-SW2-EN7 – Protocol 3000...
  • Page 64 7 – Timeout 8 – Error kds_mode – Action (state) for KDS-ACTION Set action to perform #KDS-ACTION kds_mode<CR> ~nn@KDS-ACTION Stop the encoder/decoder: by encoder/decoder. kds_mode<CR><LF> encoder/decoder #KDS-ACTION 0<CR> 0 – Stop 1 – Play 2 – Save config KDS-SW2-EN7 – Protocol 3000...
  • Page 65 TTL value value. Streaming Method. #KDS-MULTICAST?<CR> ttl - Time to Live of the streamed packets. value – Streamer Decoder Aspect KDS-RATIO? Get aspect ratio. #KDS-RATIO?<CR> ~nn@KDS-RATIO Get Aspect Ratio value<CR><LF> Ratio #KDS-RATIO?<CR> width:height, for example “16:9” KDS-SW2-EN7 – Protocol 3000...
  • Page 66 1 = No VLAN tag KDS-VLAN- Get vlan tag of #KDS-VLAN-TAG? gw_type<CR> ~nn@KDS-VLAN-TAG gw_type: Get control vlan tag: 0 – Control TAG? gateway port. gw_type,tag_id<CR><LF> #KDS-VLAN-TAG? 0<CR> tag_id – vlan tag (2 to 4093) 1 = No VLAN tag KDS-SW2-EN7 – Protocol 3000...
  • Page 67 It is not mandatory to enable the permission system in order to use the device In each device, some connections allow logging in to different levels. Some do not work with security at all. Connection may logout after timeout. KDS-SW2-EN7 – Protocol 3000...
  • Page 68 Reset machine #NAME-RST<CR> ~nn@NAME-RST Reset the machine name (DNS) name to ok<CR><LF> (S/N last digits are 0102): factory #NAME-RST default.NOTE: kramer_0102<CR> Factory default of machine (DNS) name is “KRAMER_” + 4 last digits of device serial number. KDS-SW2-EN7 – Protocol 3000...
  • Page 69 IP address (TCP:5000,0.0.0.0:0), with<CR><LF>. client_port - Client port LISTEN], state – listen or established The response format [(TCP:80,192.168.114.3:5240 lists signal IDs 0),ESTABLISHED],[(TCP:500 separated by 0,192.168.1.100:51647) commas. ,ESTABLISHED]<CR><LF> This is an Extended Protocol 3000 command. KDS-SW2-EN7 – Protocol 3000...
  • Page 70 Windows, disconnect USB connections immediately after running this command. If the port was locked, disconnect and reconnect the cable to reopen the port. ROLLBACK Rollback firmware to #ROLLBACK<CR> ~nn@ROLLBACK Perform firmware rollback: standby version. ok<CR><LF> ROLLBACK<CR> KDS-SW2-EN7 – Protocol 3000...
  • Page 71 1 – daylight saving time UTC_off to UTC time (that it got from the time server) + 1 hour if daylight savings time is in effect. TIME command sets the device time without considering these settings. KDS-SW2-EN7 – Protocol 3000...
  • Page 72 LDFW. Reset the device to complete the process. firmware_version – XX.XX.XXXX VERSION? Get firmware version #VERSION?<CR> ~nn@VERSION Get the device firmware number. firmware_version<CR><LF> where the digit groups are: version number: major.minor.build version #VERSION?<CR> KDS-SW2-EN7 – Protocol 3000...
  • Page 73 AUDIO RS232 <index> – Indicates a specific channel number when there are multiple channels of the same type audio_level – Audio level in dB (range between -60 to +30) depending of the ability of the product KDS-SW2-EN7 – Protocol 3000...
  • Page 74 2 – USB_C IN 1 – HDMI OUT <signal_type> – Signal ID attribute: VIDEO AUDIO} <index> – Indicates a specific channel number when there are multiple channels of the same type state – OFF/ON (not case sensitive) KDS-SW2-EN7 – Protocol 3000...
  • Page 75 RS232 command. Brackets ‘[‘ and ‘]’ <index> – Indicates a specific are reserved Protocol 3000 channel number when there are characters that multiple channels of the same type define a list of parameters as in [a,b,c,d]. KDS-SW2-EN7 – Protocol 3000...
  • Page 76 <signal_type> – Signal ID attribute: is interpreted as: #X-ROUTE VIDEO out.sdi.5.video.1,in.s AUDIO di.1.video.1<CR> RS232 This is an Extended Protocol 3000 <index> – Indicates a specific command. channel number when there are multiple channels of the same type KDS-SW2-EN7 – Protocol 3000...

  • Page 77: Result And Error Codes

    (Reserved) ERR_RESERVED_8 (Reserved) ERR_RESERVED_9 (Reserved) ERR_RESERVED_10 (Reserved) ERR_RESERVED_11 (Reserved) ERR_RESERVED_12 (Reserved) ERR_EDID_CORRUPTED EDID corrupted ERR_NON_LISTED Device specific errors File has the same CRC – not changed ERR_SAME_CRC ERR_WRONG_MODE Wrong operation mode ERR_NOT_CONFIGURED Device/chip was not initialized KDS-SW2-EN7 – Protocol 3000...
  • Page 78 This limited warranty gives you specific legal rights, and you may have other rights which vary from country to country or state to state. This limited warranty is void if (i) the label bearing the serial number of this product has been removed or defaced, (ii) the product is not distributed by Kramer Electronics or (iii) this product is not purchased from an authorized Kramer Electronics reseller.
  • Page 79 SAFETY WARNING Disconnect the unit from the power supply before opening and servicing For the latest information on our products and a list of Kramer distributors, visit our website where updates to this user manual may be found. We welcome your questions, comments, and feedback.
