Using Your 7408 SDI to Analog Converter

You can use your 7408 SDI to Analog Converter to convert SDI video to
professional analog video: composite video and s-Video, or component
video (as the example in
5.1

Connecting Your 7408 SDI to Analog Converter

To connect the 7408, do the following
1. Connect the SDI source (for example, a digital camera) to the SDI
IN BNC connector. You may also connect the SDI OUT BNC
connector to an SDI acceptor (such as an SDI monitor).
2. Connect the following:
An s-video acceptor (such as an s-video monitor) to the C−Y
output BNC connectors; and/or,
A composite video acceptor, such as a composite video monitor
to the CV output BNC connector; or,
A component video acceptor, such as a VCR, to the YUV BNC
connectors
3. Connect a PC (if required) to the RS-232 port (see section 5.2).
4. Set the DIP-switches, as section
5. Connect the 12V DC power adapter to the power socket and
connect the adapter to the mains electricity.
1 Switch OFF the power on each device before connecting it to your 7408. After connecting your 7408, switch on its power
and then switch on the power on each device
Using Your 7408 SDI to Analog Converter
Figure 2
Warning:
Do not cover the 7408
illustrates).
1
:
5.2 describes.
