5.2
Setting the DIP-Switches
Configure the 7508 unit by setting the DIP-switches, as shown in
and
Figure
DIP-Switch
1
Y/C
2
RESERVED
1
3
PEDESTAL
4
STANDARD 1
5
STANDARD 2
6
STANDARD 3
7
RESERVED
8
PROGRAM
1 NTSC offsets the black level within the active video signal by 7.5 IRE when selected
8
Using Your 7508 CV/YC to SDI Converter
5.
Table 2: Setting the DIP-Switches
ON for Y/C source; OFF for CV source
OFF
ON for pedestal (7.5 IRE offset selection for NTSC); OFF for no pedestal
AUTO
NTSC
PAL
OFF
ON
OFF
OFF
OFF
ON
OFF
OFF
OFF
OFF
ON for upgrading firmware; OFF for normal use
Figure 5: DIP-Switch Settings
Set as Follows:
PAL-M
PAL-N
NTSC-4 SECAM AUTO
ON
OFF
ON
ON
OFF
OFF
OFF
ON
ON
KRAMER: SIMPLE CREATIVE TECHNOLOGY
Table 2
OFF
ON
ON
ON
ON
ON
