Chapter 3 – Using the Web Management Software
Screen Parts
Menu Bar Submenu Title
S creen Buttons
1 1 0 B
Home: Click this button to return to the Home screen.
Wizard Setup: Click this button to display the Wizard Setup screen on which you can quickly set up your MultiModem
rCell Router with basic configuration settings.
Logout: Click this button to Logout and return to the login screen.
Help: Click this button to display the Help text.
S ubmenus
1 1 1 B
The submenus display on the left side of the screen.
The following table shows the sub-menu selections under each main menu category.
IP Setup
General Configuration
HTTP Configuration
DDNS Configuration
SNTP Configuration
Static Routes
Remote Configuration
DHCP Server
Subnet Settings
Fixed Addresses
20
Submenu List
Networks &
PPP
Services
PPP Configuration Network Configuration
Wakeup on Call Service Configuration
Power On Config
Modem Commands
IPSec Serial Port
Add IKE Connection Serial Port Settings
Add Manual Connection Serial Port Configuration
Client Settings
TCP/UDP-Client Config-
uration
Server Settings
TCP/UDP-Server Config-
uration
Screen Buttons
Screen Name
Screen Input
Area
GRE
Packet Filters
Tunnels
Packet Filters GRE Tunnels
DNAT Configuration GRE Routes
Advanced
Tools Statistics & Logs
Tools Ethernet
PPP
Firmware Upgrade
Load Configuration PPP Trace
Save SysInfo
Configuration DHCP Statistics
GRE Statistics
Modem Info
Service Status
TCP/UDP Client Live Log
TCP/UDP Server Live Log
IPSec Live Log
IPSec Log Traces
