5. After clicking the Wizard Setup selection, the Wizard Setup screen displays.
W izard Setup
1 0 4 B 7 7 B
A minimum router configuration is provided using the Wizard Setup. This provides a quick way to enter and save information
needed to create a connection to the Internet. The table below provides the information for the minimum configuration.
IP Address
Mask
DNS
PPP
Dial-on-
Demand
Idle Time Out
Dial Number
APN
Init String
Authentication
Type
Username
Password
Multi-Tech Systems, Inc. MultiModem rCell User Guide
IP Configuration
The default is 192.168.2.1. To change it, simply enter your own IP address.
The default is 255.255.255.0
Enter the primary DNS IP address for the system. The default is 0.0.0.0
PPP Configuration
The default is disable. To connect to the Internet, you need to enable PPP.
Depending on the model, commands may need to be issued to the integrated cellular
modem before connecting to the wireless service. To issue commands to the integrated
cellular modem, PPP must be disabled and telnet port 5000 used.
The default is disable.
Sets the amount of time the PPP link stays active before disconnecting. Setting the value
to zero causes the link to stay active continuously.
Enter the dial number. This number connects you to the Internet.
For HSDPA, the number is *99***1#.
For GSM models, enter the APN (Access Point Name). The APN is assigned by your
wireless service provider.
For CDMA models, the APN does not apply
You can set up to 4 router initialization strings.
PPP Authentication
Click the button corresponding to the authentication protocol you want to use to
negotiate with the remote peer. PAP, CHAP, or PAP-CHAP.
Default = PAP-CHAP
Enter the PPP Username. This name authenticates the remote peer.
Enter the PPP Password. This password authenticates the remote peer.
Chapter 2 – Activation and Installation
17
