Media Compartment
Ribbon supply hub
Ribbon rewind hub
EasyCoder PX4i Bar Code Label Printer User's Guide (IPL Version)
The media compartment is covered by the side door which can
be opened 180° downwards to provide complete access to the
media and ribbon loading area. The door is held closed by a
magnetic lock. It can be completely removed by opening it and
then pulling it forward.
The media can be supplied from a rotating hub or from an
external supply of fanfolded media behind the printer. For more
information, see
"Options" on page
Slack absorber
Media Compartment
Chapter 2 — Installation
73.
Side door
Media supply
roll hub
9
