Operation
Navigation Overview
Touch any of the fields to see data on the via points starting from the first one through the final
destination.
This screen includes following data and features:
Name
Route Line
Estimated Arrival
Distance Left
Time Left
Method
Warning icons
[Settings]
[Plan on Map]
[Skip Next Via]
[Delete Route]
86
86
Description
The upper part of this screen shows your
planned route as a horizontal line. The
point at the left end represents the route
starting point and the point at the right
end represents the final destination. The
flags of the via points along the line are
separated by intervals proportional to the
distances between them.
Shows the estimated arrival time at the
final destination of the route based on
information available for the remaining
segments of the route. The calculation
cannot take into account traffic jams and
other possible delays.
Shows distance left to final destination.
Shows the time needed to reach the final
destination of the route based on
information available for the remaining
segments of the route. The calculation
cannot take into account traffic jams and
other possible delays.
This field shows how the route was
calculated.
The route type (fast, short, simple, or
economical) is displayed here.
In these square fields graphical symbols
are displayed in the case that warnings
are attached to the planned route. These
are warnings, so icons always show
information for the whole route, even if
the data fields only display values from
your present position to a via point.
Appears only if at least one via point
exists.
Only appears when the route contains no
via points.
Function
Touch this field to change the
content of all data fields to via point
information.
Touch this field to change the
content of all data fields to via point
information.
Touch this field to change the
content of all data fields to via point
information.
Touch this field to change the
content of all data fields to via point
information.
Touch this field to change the
content of all data fields to via point
information.
Touch any of the icons for an
explanation.
Opens the Route planning options
screen from the Settings menu.
Opens the Map screen designed for
route planning.
Deletes the next via point from the
route.
Deletes the active route.
