DVD Navigation System with 6.5" Wide TFT Display and DVD Multi-Source Receiver
INSTALLATION MANUAL
Be sure to read this installation manual thoroughly prior to installation and making connections. If
installation methods or non-standard parts not specified in this installation manual are used, accidents
or injury may result.
Professional installation is recommended, contact the place of purchase to schedule an appointment.
After reading the owner's manual and the installation manual thoroughly, keep them in a safe place for
later reference.
To dealers:
Give this installation manual to the customer after installation and all connections have been
completed.
Contents
Contents
Components
Before
For your safety in using the AVN50D
installation
Installation Diagram
Names and functions of terminals
Connections
Connecting the vehicle speed pulse, parking brake, and reverse wires
System connection example
Installing the GPS antenna
Installation
Installing the main unit
MODEL
2
3
5
6
10
12
13
16
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Eclipse AVN50D
Summary of Contents for Eclipse AVN50D
- Page 1 Give this installation manual to the customer after installation and all connections have been completed. Contents Contents Components Before For your safety in using the AVN50D installation Installation Diagram Names and functions of terminals Connections Connecting the vehicle speed pulse, parking brake, and reverse wires...
- Page 2 Components Components Check that all of the following components are present Check that all of the following components are present Main unit components Main unit x 1 Interconnecting wires Interconnecting wires Interconnecting wires (Power and front speaker connector) (Rear speaker connector) (Steering remote control (10P) x 1 (6P) x 1...
- Page 3 A VN50D Warnings and caution signs, illustrated bellow, are posted throughout this manual as well as on the AVN50D. They show safe and correct ways to handle the main unit to prevent personal injury to you and others and avoid damage to property.
- Page 4 • • If this main unit is not connected properly, a short with Eclipse main units and can damage the main circuit, fire, or accident may occur. unit. Prior to powering up the main unit, please make sure the main unit is properly grounded with the •...
- Page 5 Installation Diag Installation Diag GPS antenna (When installing inside the vehicle) GPS antenna (When installing outside the vehicle) Main unit • • If installing the GPS antenna inside the vehicle, the location and the slope of the vehicle's windshield will determine the accuracy of the GPS antenna to receive the GPS signal. If the GPS antenna location inside the vehicle is hindering the accuracy of the GPS antenna, then you may want to install the antenna outside of the vehicle.
- Page 6 • • Use supplied wire harness with this main unit. Other manufacturers may use a similar wire harness connector but pin configurations are incorrect for use with Eclipse main units and can damage the main unit. Prior to powering up the main unit, please make sure the main unit is properly grounded with the vehicle chassis.
- Page 7 Wire colors and connection points for connection wires Never connect the power supply to the speaker wires (No.6 and No.7), otherwise it will cause damage to the main unit. Caution B+ (Yellow) Connect where power is constantly available, regardless of the ignition key's position. ACC (Red) Connect where the power comes on when the ignition is in the ACC position.
- Page 8 E-LAN terminal (13P) Connect to the E-LAN terminal of the CD changer, etc. VTR output terminal (Yellow) Connect to the monitor with video input. Back-eye camera external input terminal (4P) Used with the Eclipse back-eye camera (sold separately). - 8 -...
- Page 9 - Vehicle connections - • • You will need to purchase the necessary vehicle component adapter wire for the vehicle so that the power supplies can be utilized. (Contact the dealer for further details.) • • Be sure to wrap the connection wires with electrical tape or another insulation method to insulate them. - Example of using vehicle adapter wires - Vehicle harness Power supplies...
- Page 10 The locations where the vehicle speed pulse signal wire, parking brake signal wire, and reverse wire may vary depending on the vehicle model and grade. Ask the car dealer or your nearest Eclipse dealer for details. - A connecting point for the vehicle speed pulse signal (example) -...
- Page 11 - A connecting the point for parking brake (example) - Hand-operated Parking brake Attach a splicing Parking brake connector at this location. Signal Wire Parking brake signal wire Foot-operated Parking brake - A connecting point for the reverse signal (example) - Attach a splicing •...
- Page 12 System connection e xample System connection e xample • • Never cut the insulation on the power wire or use it to power any other main unit. If the rated current capacity of the power wire is exceeded, fire and electric shocks may result. •...
- Page 13 Installing the GPS antenna Installing the GPS antenna Notes on installation • • The wires should be bound together with tape or a similar securing method (example: wire ties) so that they do not interfere with driving. If it becomes wound or entangled around parts such as the steering wheel, shifting lever, or brake pedal, accidents may result.
- Page 14 - Installation inside the vehicle (example) - Choose an installation location on the dashboard which is flat and has a clear view of the sky. Ground plate GPS antenna • • Select a location that is at least 20 in. away from the main unit.
- Page 15 - Installation outside the vehicle (example) - Choose an installation location where the GPS antenna can be attached securely. Remove the backing paper from the body GPS antenna protective sheet and attach the sheet to the Body protective sheet (clear) vehicle.
- Page 16 Installing the main unit Installing the main unit - Installation angle - To maintain proper function, the main unit must be Front mounted less than 30 degrees. If the angle is in excess of 30 degrees, DVD/CD skipping and improper DVD/CD ejection may occur. 30˚...
