NetDisk™ Wireless User Manual

3-7. Routing

This function allows packet data, bound for a specific destination IP address, to go through another
gateway instead of NetDisk Wireless.
On the Routing screen, you can set the routing mode and settings of the Router. Gateway mode is
recommended for most users.
Important: This function can only be used if there are more than two gateways.
1. Click Routing Table under the Routing heading
2. Input the IP address and Subnet Mask number of the destination host or network at
Destination (Dst.) boxes
3. Input the alternate gateway address that data will pass through, (instead of NetDisk Wireless)
at the Gateway IP box.
Click ADD after entering each entry. Only Click DEL to cancel unsaved changes.
4. After setup of all desired configurations, Click APPLY.
Destination IP Address : The address of the network or host to which the static route is
Subnet Mask
Gateway
XIMETA, Inc
[Figure 3-20. Routing Table]
Routing Table
assigned.
: Determines which portion of an IP address is the network or host.
: IP address of the gateway device that allows for contact between
the Router and the network or host.
28
