NetDisk™ Wireless User Manual
The NetDisk Wireless has been designed to be functional right out of the box with the default
settings. The default settings require that your networked PCs are configured to automatically
assign IP. You may also manually configure NetDisk Wireless from WEB Manager by following
the steps below.
Accessing WEB Manager:
1. Open your web browser and Type 192.168.1.1 in the Address Box.
2. Click Enter.
3. Enter admin in the User Name Box and admin in the Password Box.
By Default, the User Name and Password are both admin (You can
change this later).
4. Click OK. You will see the following figure.
XIMETA, Inc
Chapter 3. Advanced Configuration of
NetDisk Wireless Settings
[Figure 3-1. Password prompt for NetDisk Wireless]
[Figure 3-2. LAN Setup of NetDisk Wireless]
Network Direct Attached Storage / NDAS™
13 www.XIMETA.com
