Summary of Contents for Clarke CMSF110
- Page 1 MULTI PURPOSE CIRCULAR SAW Model No: CMSF110 Part No: 6462162 OPERATING & MAINTENANCE INSTRUCTIONS GC0111...
-
Page 2: Introduction
INTRODUCTION Thank you for purchasing this CLARKE multi purpose circular saw. The saw can be used for cutting almost any material up to a thickness of 35 mm, including ferrous and non-ferrous metals, timber, plywood man made boards, bakelite and plastics etc. -
Page 3: Table Of Contents
CONTENTS Introduction .................... 2 Guarantee ....................2 Environmental Protection ..............2 Parts & Service ..................2 Table of Contents ................... 3 General Safety Precautions ..............4 Electrical Connections ................7 Introduction .................... 8 Preparation for Use ................9 Operation ..................... 10 Changing the Blade ................ -
Page 4: General Safety Precautions
GENERAL SAFETY PRECAUTIONS Important Note: Although the operation manual contains extensive instruction on safe working with power tools, every power tool involves a certain residual risk which cannot be completely excluded. Power tools must therefore always be operated with caution. WORK AREA SAFETY 1. - Page 5 4. Remove any adjusting key or wrench before turning the power tool on. A wrench or a key left attached to a rotating part of the power tool may result in personal injury. 5. Do not overreach. Keep proper footing and balance at all times. This enables better control of the power tool in unexpected situations.
- Page 6 PRECAUTIONS SPECIFIC TO CIRCULAR SAWS 1. ALWAYS wear ear protectors/defenders during continuous use as the noise level of this machine can exceed 85dB (A). The use of safety glasses and a respiratory mask as protection from airborne particles is recommended. 2.
-
Page 7: Electrical Connections
ELECTRICAL CONNECTIONS WARNING! Read these electrical safety instructions thoroughly before connecting the product to the mains supply. Before switching the machine on, make sure that the voltage of your electricity supply is the same as that indicated on the rating plate. This product is designed to operate using 230 VAC mains power. -
Page 8: Introduction
INTRODUCTION CONTENTS 1 x Multi-Purpose Circular Saw 1 x 110 mm dia Blade (fitted) 1 x 4.0 mm Hexagon Key (in storage socket) 1 x Instruction Manual Power Cable Sole Plate Trigger Lower Blade Guard Trigger Safety Button Saw Blade Front Handle Lower Guard Lever Spindle Lock... -
Page 9: Preparation For Use
PREPARATION FOR USE WARNING! THIS APPLIANCE SHOULD NOT BE USED BY ANYONE NOT EXPERIENCED IN THE USE AND OPERATION OF POWER TOOLS BEFORE STARTING WORK IMPORTANT! Before use, ensure the workpiece is perfectly secure, and there is sufficient clearance BENEATH the workpiece so that there is no possibility of the saw blade coming into contact with any other object. -
Page 10: Operation
OPERATION STARTING A CUT 1. Place the leading edge of the sole plate on the top face of the workpiece, ensuring the saw blade is NOT making contact. 2. Push IN and hold the trigger safety button on the side of handle to either the left or right side. - Page 11 Not supporting the workpiece securely. Cutting warped or wet timber. Forcing the saw through the cut. Failure to fit the saw blade correctly. Using the wrong saw blade. To reduce the possibility of kickback occurring, always maintain a firm grip on the saw and position yourself to resist kickback forces.
-
Page 12: Changing The Blade
5. Tighten the hex bolt using the hex key. Return the hex key to its storage socket in the saw body. CAUTION; INSTALLING THE BLADE THE WRONG WAY ROUND MAY RESULT IN DAMAGE TO THE BLADE. Note: Replacement blades are available from your CLARKE dealer; part no 6462168. -
Page 13: Maintenance
Overloading the machine will also cause overheating. Do not use for heavy duty work and do not apply excessive pressure. EXCESSIVE SPARKING OCCURS This indicates worn brushes which can be easily replaced by your CLARKE dealer. SAW DOES NOT OPERATE WHEN SWITCHED ON Check to ensure the fuse is sound and replace if necessary. -
Page 14: Technical Specification
TECHNICAL SPECIFICATION , s l Please note that the details and specifications contained herein, are correct at the time of going to print. However, CLARKE International reserve the right to change specifications at any time without prior notice. -
Page 15: Parts Lists And Diagrams
ACCESSORIES Replacement Cutting Blade Part No: 6462168 The use of parts other than genuine Clarke replacement parts may result in possible safety hazards or decreased machine performance, and will invalidate your warranty. Contact your Clarke dealer for further information. - Page 16 PARTS LIST i l i i l i i l i...
-
Page 17: Parts Diagram
PARTS DIAGRAM When ordering spare parts for this product, please quote the prefix TMC ahead of the part number listed above. -
Page 18: Declaration Of Conformity
DECLARATION OF CONFORMITY... - Page 19 NOTES _________________________________________________________________________ _________________________________________________________________________ _________________________________________________________________________ _________________________________________________________________________ _________________________________________________________________________ _________________________________________________________________________ _________________________________________________________________________ _________________________________________________________________________ _________________________________________________________________________ _________________________________________________________________________ _________________________________________________________________________ _________________________________________________________________________ _________________________________________________________________________ _________________________________________________________________________...
