COMPOUND MITRE SAW
Model CMS251
OPERATION & MAINTENANCE
INSTRUCTIONS
©
0801

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Woodworker CMS251 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Clarke Woodworker CMS251

  • Page 1 COMPOUND MITRE SAW Model CMS251 OPERATION & MAINTENANCE INSTRUCTIONS © 0801...
  • Page 2 © Copyright Clarke International. All rights reserved, August 2001...
  • Page 3: Table Of Contents

    Thank you for purchasing this CLARKE 10 inch Compound Mitre Saw. This extremely versatile machine is designed for DIY/Hobby use and for use by tradesmen in a light industrial environment Before operating the machine, please read this leaflet thoroughly and carefully follow all instructions.
  • Page 4: Safety Precautions

    GENERAL SAFETY RULES FOR OPERATING MACHINERY WARNING: As with all machinery, there are certain hazards involved with their operation and use. Exercising respect and caution will considerably lessen the risk of personal injury. However, if normal safety precautions are overlooked or ignored, personal injury to the operator or damage to property, may result.
  • Page 5 11. REMOVE ADJUSTING KEYS AND WRENCHES. Form the habit of checking to see that keys and adjusting wrenches are removed from the machine before switching on. 12. Do not operate machine while under the influence of DRUGS, ALCOHOL OR ANY MEDICATION. 13.
  • Page 6: Additional Precautions For Table/Mitre Saws

    10. Use ONLY approved replacement saw blades. Contact your local CLARKE dealer for advice. The use of inferior blades may increase the risk of injury. 11. DO NOT saw any material that does not have a flat surface on which to bear.
  • Page 7: Electrical Connections

    ELECTRICAL CONNECTIONS Connect the mains lead to a standard, 230 Volt (50Hz) electrical supply through an approved 13 amp BS 1363 plug, or a suitably fused isolator switch. WARNING! THIS APPLIANCE IS DOUBLE INSULATED IMPORTANT: The wires in the mains lead are coloured in accordance with the following code: Blue Neutral...
  • Page 8: Principal Parts

    PRINCIPAL PARTS OF THE SAW Fig.1 Fig.2...
  • Page 9: Features

    LEGEND A Cutting Head Release Lever Table Release Lever B Trigger Switch (ON/OFF) K Pointer C Cutting Head Locking Pin Stabiliser D Table Locking Knob M Bevel Scale Work Clamp N Bevel Locking Knob Back Fence O Head Return Spring Tension Adjuster G Table Insert P Cutting Head Stop Screw H Front Mounting Hole...
  • Page 10: Assembly And Installation

    On receipt inspect the machine to ensure that all parts are accounted for and that no damage was incurred during transit. Any deficiency or damage should be reported to your CLARKE dealer immediately. The main body of the saw is fully assembled and adjusted at the factory. It is necessary only to fit the accessories supplied as follows: Fig.3...
  • Page 11: Operation

    OPERATION A. Cross Cutting (at 90 ) Ref: Figs 1 & 2 First, set the work in place. Clamp it firmly against the table and back fence. Check the security of the Bevel Locking Knob (N) and tighten if necessary, also ensure the table is locked using the Table Locking Knob (D).
  • Page 12: Bevel Cutting

    C. Straight Bevel Cutting As with Mitre Cutting, this is a cross cutting operation, except that the blade is not perpendicular to the table (see illustration) Fig.6 Ensure the table is set so that the table pointer lines up with the zero on the scale on the bed.
  • Page 13: Maintenance

    Should the motor not function normally, it is possible that it has become clogged with saw dust, in which case, it will be necessary to disassemble the motor in order to clean the various components. Contact your CLARKE dealer for advice. 2. Changing the Saw Blade IMPORTANT: Exercise extreme care when handling the saw blade.
  • Page 14 Fig.11 Remove the screw securing the upper plastic guard, arrowed in Fig.11, and pull away the guard. Fig.12 Unscrew and remove the Blade securing screw using the claw and box spanners provided, taking great care to avoid damaging your hand on the saw blade teeth.
  • Page 15: Motor Brush Renewal

    3. Renewing Motor Brushes Eventually, the motors’ carbon brushes will need replacing. This task may be carried out quickly and easily as follows. Remove the two cross head Fig.14 screws, securing the motors’ end cover, and pull off the cover. Disconnect the spade connector, shown in Fig.
  • Page 16: Adjustments

    ADJUSTMENTS Ref: Fig 16 It may be necessary from time to time, to check various settings and make appropriate adjustments. a. Squareness of Blade It is most important to check that the blade is exactly perpendicular to the table. To do this, place a small square on Fig.16 the table and bring it up to the blade, checking to see if it is square.
  • Page 17: Specifications

    Part Number ............6500768 Please note that the details and specifications contained herein, are correct at the time of going to print. However, CLARKE International reserve the right to change specifications at any time without prior notice. Always consult the machine’s data plate...
  • Page 18: Parts And Service Contacts

    TMCCMS25139 PARTS & SERVICE CONTACTS For Spare Parts and Service, please contact your nearest dealer, or CLARKE International, on one of the following numbers. PARTS & SERVICE TEL: 020 8988 7400 PARTS & SERVICE FAX: 020 8558 3622 e-mail as follows: PARTS: Parts@clarkeinternational.com...
  • Page 19: Parts Diagram

    PARTS DIAGRAM...
