Summary of Contents for Clarke woodworker CMS10 6501305
- Page 1 10” COMPOUND MITRE SAW 10” COMPOUND MITRE SAW Model CMS10 Part Number 6501305 Operating & Maintenance Instructions © 02/08...
-
Page 2: Specifications
32mm Please note that the details and specifications contained herein, are correct at the time of going to print. However, CLARKE International reserve the right to change specifications at any time without prior notice. Always consult the machine’s data plate DO NOT dispose of theis product with general household waste. -
Page 3: Table Of Contents
Thank you for purchasing this CLARKE 10 inch Compound Mitre Saw which is designed for DIY/hobby and medium trade use only. Before operating the Mitre Saw please read this leaflet thoroughly and carefully follow all instructions. This will ensure the safety of yourself and that of others around you, and you can also look forward to the machine giving you long and satisfactory service. -
Page 4: Safety Precautions
SAFETY PRECAUTIONS GENERAL SAFETY RULES FOR OPERATING MACHINERY WARNING: As with all machinery, there are certain hazards involved with their operation and use. Exercising respect and caution will considerably lessen the risk of personal injury. However, if normal safety precautions are overlooked or ignored, personal injury to the operator or damage to property, may result. - Page 5 11. REMOVE ADJUSTING KEYS AND WRENCHES. Form the habit of checking to see that keys and adjusting wrenches are removed from the machine before switching on. 12. DRUGS, ALCOHOL, MEDICATION. Do not operate machine while under the influence of drugs, alcohol or any medication. 13.
-
Page 6: Additional Precautions For Mitre Saws
DO NOT operate the machine with the guards removed. They must all be in place and securely fastened when performing any operation. 10. Use ONLY approved replacement saw blades. Contact your local CLARKE dealer for advice. The use of inferior blades may increase the risk of injury. -
Page 7: Electrical Connections
ELECTRICAL CONNECTIONS Connect the mains lead to a standard, 230 Volt (50Hz) electrical supply through an approved 13 amp BS 1363 plug, or a suitably fused isolator switch. WARNING! THIS APPLIANCE IS DOUBLE INSULATED IMPORTANT: The wires in the mains lead are coloured in accordance with the following code: Blue Neutral... -
Page 8: Principle Parts
PRINCIPAL PARTS OF THE SAW Fig.1 Fig.2... -
Page 9: Features
FEATURES As its’ name implies, the machine is a Bevel/Mitre Saw, capable of straight cross cutting, and cutting bevels and mitres, or a combination of the two. The main arm, or Cutting Head, carries the motor and the tungsten carbide saw blade. -
Page 10: Assembly
1 x rear support with nut and bolt 2 x work supports Any deficiency or damage should be reported to your CLARKE dealer immediately. Mount the machine on a firm solid base that will not move under load. Ensure there is an appropriate electrical supply, and adequate lighting, so that you will not be working in your own shadow. -
Page 11: Mitre Cutting
NOTE: If the workpiece is not entirely straight, ensure that the portion at either side of the intended cut rests firmly against the table and back fence. When satisfied, make a final check to ensure that all safety precautions are being complied with, then pull and hold the trigger and allow the blade to reach full speed. -
Page 12: Bevel Cutting
C. Straight Bevel Cutting As with Mitre Cutting, this is a cross cutting operation, except that the blade is not perpendicular to the table, (see fig. 5). Ensure the table is set to 0 , and is Fig.5 locked in place using the table knob. The bevel adjuster is factory set so that when the head is tilted to its fullest extent the blade will cut a... -
Page 13: Maintenance
Should the motor not function normally, it is possible that it has become clogged with saw dust, in which case, it will be necessary to disassemble the motor in order to clean the various components. Contact your CLARKE dealer for advice. 2. Changing the Saw Blade IMPORTANT: Exercise extreme care when handling the saw blade. - Page 14 Additionally, the blade MUST be rated with a maximum speed greater that 4850RPM Please note that spare blades are available from Clarke International. Please see your Clarke dealer. Replace the outer flange and screw in the centre bolt, remembering it has a left hand thread - i.e.
-
Page 15: Adjustments
3. Carbon Brushes Replacement A spare pair of carbon brushes are supplied with the machine. Should it become necessary to change these, evidenced by erratic performance, then simply unscrew the brush holder plugs, ensuring the machine is disconnected from the mains supply, and pull out the worn brushes. -
Page 16: Parts Lists And Diagrams
PARTS DIAGRAM... - Page 17 PARTS LIST Description Part No. No. Description Part No. Lengthening Nut GRCMS1051 Circlip For Shaft GRCMS1001 Armor GRCMS1052 Pressure Rod GRCMS1002 Spring GRCMS1053 Screw M4×55 GRCMS1003 Spring Lock Washer GRCMS1004 Frame GRCMS1054 Screw M4×10 GRCMS1005 Copper Washer GRCMS1055 Cable Clip GRCMS1006 Spring Lock Washer GRCMS1056...
