Summary of Contents for Allied Telesis AT-FS713FC/xx

  • Page 1: Installation Guide

    AT-FS713FC/xx AT-FS717FC/xx 10/100 Mbps Ethernet Switches Installation Guide PN 613-50268-00 Rev A...
  • Page 2 Copyright 2001 Allied Telesyn International Corp. 960 Stewart Drive Suite B, Sunnyvale CA 94085, USA All rights reserved. No part of this publication may be reproduced without prior written permission from Allied Telesyn International Corp. Ethernet is a registered trademark of Xerox Corporation. All other product names, company names, logos or other designations mentioned herein are trademarks or registered trademarks of their respective owners.
  • Page 3: Electrical Safety And Emission Compliance Statement

    Electrical Safety and Emission Compliance Statement Standards: This product meets the following standards. U.S. Federal Communications Commission RADIATED ENERGY Note: This equipment has been tested and found to comply with the limits for a Class A digital device pursuant to Part 15 of FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.
  • Page 5: Table Of Contents

    Table of Contents Electrical Safety and Emission Compliance Statement ......iii Welcome to Allied Telesyn ................. vii Where to Find Web-based Guides ..............vii Document Conventions ..................vii Contacting Allied Telesyn Technical Support..........viii Online Support ..................viii Telephone and Fax Support..............viii Technical Support E-mail Addresses ............ix Returning Products ...................
  • Page 6 Table of Contents Chapter 2 Installing the Switch ................... 11 Reviewing Safety Guidelines ................11 Verifying the Package Contents ..............12 Planning the Installation ................. 13 Selecting a Site ....................14 Installing the Switch On a Table or Desktop ..........15 Wall-mounting the Switch ................
  • Page 7: Welcome To Allied Telesyn

    Welcome to Allied Telesyn The guide contains instructions on how to install the AT-FS713FC/xx and AT-FS717FC/xx Series Ethernet Switches. Where to Find Web-based Guides The Allied Telesyn web site at www.alliedtelesyn.com provides you with an easy way to access the most recent documentation, software, and technical information for all of our products.
  • Page 8: Contacting Allied Telesyn Technical Support

    Contacting Allied Telesyn Technical Support You can contact Allied Telesyn technical support online or by telephone, fax, or e-mail. Online Support You can request technical support online by filling out the Technical Enquiry Form or by accessing the Knowledge Base. You can use the Knowledge Base to submit questions to our technical support staff and review answers to previously asked questions.
  • Page 9: Technical Support E-Mail Addresses

    AT-FS713FC/xx and AT-FS717FC/xx Series Installation Guide Technical Support E-mail Addresses United States and Canada TS1@alliedtelesyn.com Latin America, Mexico, Puerto Rico, Caribbean, and Virgin Islands latin_america@alliedtelesyn.com Europe support_europe@alliedtelesyn.com Returning Products Products for return or repair must first be assigned a Return Materials Authorization (RMA) number.
  • Page 10: For Sales Or Corporate Information

    For Sales or Corporate Information You can contact Allied Telesyn for sales or corporate information at the location listed below: Allied Telesyn International Corp. 19800 North Creek Parkway, Suite 200 Bothell, WA 98011 Tel: 1 (425) 487-8880 Fax: 1 (425) 489-9191 Tell Us What You Think If you have any comments or suggestions on how we might improve this or other Allied Telesyn documents, please fill out the General Enquiry Form...
  • Page 11: Chapter 1 Overview

    The fiber optic port operates at 100 Mbps and features half- and full-duplex operation. The twisted pair port operates at 10 or 100 Mbps and auto- negotiates the duplex mode. The AT-FS713FC/xx and AT-FS717FC/xx Series Switches are easy to install and do not require software configuration or management.
  • Page 12 Figure 1 illustrates the front and back panels of an AT-FS713FC/xx Series Switch. LEDs Duplex Switch Front Panel AT-FS713FC/MT 100FX 10/100TX 10Base-T / 100Base-TX 12 Port Fast Ethernet Switch with 100FX Uplink LNK/ 100M 100FX DUPLEX LNK/ LNK/ HALF FULL...
  • Page 13 AT-FS713FC/xx and AT-FS717FC/xx Series Installation Guide Table 1 lists the maximum operating distances for the AT-FS713FC/xx Series Switches. Table 1 AT-FS713FC/xx Series Maximum Operating Distances 10/100Base-TX 100Base-FX Model Maximum Maximum Connector Connector Operating Distance Operating Distance AT-FS713FC/FJ RJ-45 100 m (328 ft) 2 km (1.2 mi)
  • Page 14: Features

    FJ, LC, MT, SC, ST, or VF fiber optic connector Store and forward Ethernet packet handling MAC address table with a capacity of 4,000 addresses Status LEDs Table 3 defines the LEDs on the AT-FS713FC/xx and AT-FS717FC/xx Series Switches. Table 3 LEDs Color...
  • Page 15: Twisted Pair Ports

    AT-FS713FC/xx and AT-FS717FC/xx Series Installation Guide Twisted Pair Ports The AT-FS713FC/xx and AT-FS717FC/xx Series Switches have twelve and sixteen 10/100Base-TX twisted pair ports, respectively. Port Speed The twisted pair ports are compliant with the 10Base-T and 10Base-TX standards and are capable of either 10 Mbps or 100 Mbps operation. The ports are IEEE 802.3u auto-negotiation compliant.
  • Page 16: Fiber Optic Port

    The AT-FS713FC/xx and AT-FS717FC/xx Series Switches can operate in either half- or full-duplex mode. To set the duplex mode on the fiber optic port, slide the 100FX DUPLEX switch UP (half-duplex) or DOWN (full-duplex).
  • Page 17: Mac Address Table

    MAC address table has exceeded its storage limit. Store and Forward The AT-FS713FC/xx and AT-FS717FC/xx Series Switches support store and forward switching at Fast Ethernet full-wire speed in 100 Mbps, half- or full- duplex mode. Packets entering each port are stored in buffers. Once the full packet is received, the switch will forward or discard the packet, depending on its destination address and error status.
  • Page 18: Network Topologies

    Network Topologies The AT-FS713FC/xx or AT-FS717FC/xx Series Switches can be used in several network topologies. Some of these topologies are described below. Workgroup Topology Figure 3 illustrates a workgroup topology where each end-node is connected directly to a port on an AT-FS713FC/SC switch, giving each end-node a dedicated 10 Mbps or 100 Mbps link.
  • Page 19: Ethernet Hub Workgroup Topology

    AT-FS713FC/xx and AT-FS717FC/xx Series Installation Guide Ethernet Hub Workgroup Topology Figure 4 illustrates an Ethernet hub workgroup topology where an AT-FS713FC/SC is used to connect together four 10/100 Mbps Ethernet hubs. This allows the switch to function as a bridge between the different workgroups by controlling the flow of data between the workgroups.
  • Page 20: Backbone Topology

    Backbone Topology If your network consists of several AT-FS713FC/xx or AT-FS717FC/xx Series Switches, then you will probably want to connect them together to form an integrated network. Here the fiber optic ports can be extremely useful. You can use the ports to create a fiber optic backbone. With a maximum operating distance of 2 kilometers (1.2 miles), the ports can be used to connect together...
  • Page 21: Installing The Switch

    Chapter 2 Installing the Switch This chapter contains desktop and wall-mounting installation instructions for an AT-FS713FC/xx or AT-FS717FC/xx Series Switch. Reviewing Safety Guidelines Please review the following safety guidelines before you begin to install the switch. Warning Class 1 laser product.
  • Page 22: Verifying The Package Contents

    Make sure the following items are included in your package. If any item is missing or damaged, contact your Allied Telesyn sales representative for assistance. One AT-FS713FC/xx or AT-FS717FC/xx Series Switch Power cord Four protective feet (for desktop use only)
  • Page 23: Planning The Installation

    AT-FS713FC/xx and AT-FS717FC/xx Series Installation Guide Planning the Installation Be sure to observe the following guidelines when planning the installation of your switch. The end-node connected to the 100Base-FX fiber optic port must be able to operate at 100 Mbps.
  • Page 24: Selecting A Site

    Refer to Table 6 for the cabling specifications for the fiber optic port operating in half-duplex mode. Table 6 100Base-FX Fiber Optic Ports (Half-duplex) Number of Media Maximum Operating Connected Devices Converters Distance One Media Converter Inline Switch to switch 372 m (1,221 ft) Workstation to switch 372 m (1,221 ft)
  • Page 25: Installing The Switch On A Table Or Desktop

    AT-FS713FC/xx and AT-FS717FC/xx Series Installation Guide Installing the Switch On a Table or Desktop To wall-mount the switch, refer to “Wall-mounting the Switch” on page 16. To install the switch on a table or desktop, perform the following procedure: Remove all components from the shipping package and store the packaging material in a safe location.
  • Page 26: Wall-Mounting The Switch

    Wall-mounting the Switch The switch can be mounted either vertically or horizontally on a wall using the keyholes on the bottom of the chassis. For wall-mount installation, you will need two panhead screws and plastic anchors. To wall-mount the switch, perform the following procedure: If attached, remove the rubber feet, data cables, and power cord from the switch.
  • Page 27: Warranty Registration

    AT-FS713FC/xx and AT-FS717FC/xx Series Installation Guide Warranty Registration When you have finished installing the product, register your product by completing the enclosed warranty card and sending it in. You can also fill out the registration online by selecting “Warranties” under “Support & Services”...
  • Page 29: Chapter 3 Troubleshooting

    Chapter 3 Troubleshooting Follow the guidelines below to test and troubleshoot the installation in the event a problem occurs. If the PWR LED is OFF, do the following: Make sure that the power cord is securely connected to the wall outlet and the power connector on the back of the switch.
  • Page 30 If the LNK/ACT LED for the fiber optic port is OFF, do the following: Verify that the end-node connected to the port is ON and is operating properly. Check that the fiber optic cable is securely connected to the port on the switch and to the port on the end-node.
  • Page 31: Technical Specifications

    Appendix A Technical Specifications Physical Dimensions: W x D x H 1.7 cm x 17.9 cm x 9.8 cm (0.7 in x 7 in x 3.9 in) Weight: 0.42 kg (0.9 lbs) Temperature Maximum Operating: 0° to 40° C (32° to 104° F) Maximum Storage: -25°...
  • Page 32: Fiber Optic Port Specifications

    Fiber Optic Port Specifications Table 7 through Table 10 list the specifications for the fiber optic port. Table 7 Fiber Optic Transmitter Fiber Launch Power (dBm) Optic Optical Model Fiber Type Diameter Frequency Maximum Average Minimum (microns) All models Multimode 50/125 1310 nm -14.0...
  • Page 33: Pinout Assignments

    AT-FS713FC/xx and AT-FS717FC/xx Series Installation Guide Table 10 Fiber Optic Loss Specification (Benchmark) Fiber Optic Optical Typical Loss Worst Case Fiber Type Bandwidth Diameter Frequency Factor Loss Factor Multimode 50/125 1310 nm 1.00 dB/km 1.50 dB/km 400 Mhz-km microns 62.5/125 1310 nm 1.00 dB/km...
  • Page 35: Translated Electrical Safety Emission Information

    Appendix B Translated Electrical Safety Emission Information Important: This appendix contains multiple-language translations for the safety statements in this guide. Wichtig: Dieser Anhang enthält Übersetzungen der in diesem Handbuch enthaltenen Sicherheitshinweise in mehreren Sprachen. Vigtigt: Dette tillæg indeholder oversættelser i flere sprog af sikkerhedsadvarslerne i denne håndbog.
  • Page 36 Standards: This product meets the following standards. U.S. Federal Communications Commission RADIATED ENERGY Note: This equipment has been tested and found to comply with the limits for a Class A digital device pursuant to Part 15 of FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.
  • Page 37 AT-FS713FC/xx and AT-FS717FC/xx Series Installation Guide All Countries: Install product in accordance with local and National Electrical Codes. Normen: Dieses Produkt erfüllt die Anforderungen der nachfolgenden Normen. Hochfrequenzstörung FCC Part 15 (Class A), EN55022 (Class A), EN61000-3-2, EN61000-3-3 Warnung: Bei Verwendung zu Hause kann dieses Produkt Funkstörungen hervorrufen.
  • Page 38 ELEKTRISKE FORHOLDSREGLER Advarsel: RISIKO FOR ELEKTRISK STØD For at forebygge ELEKTRISK stød, undlad at åbne apparatet. Der er ingen indre dele, der kan repareres af brugeren. Denne enhed indeholder LIVSFARLIGE STRØMSPÆNDINGER og bør kun åbnes af en uddannet og kvalificeret tekniker. For at undgå risiko for ELEKTRISK STØD, afbrydes den elektriske strøm til produktet, før LAN-kablerne monteres eller afmonteres.
  • Page 39 AT-FS713FC/xx and AT-FS717FC/xx Series Installation Guide Opgelet: De ventilatiegaten mogen niet worden gesperd en moeten de omgevingslucht ongehinderd toelaten voor afkoeling. Bedrijfstemperatuur: De omgevingstemperatuur voor dit produkt mag niet meer bedragen dan 40 graden Celsius. Alle Landen: het toestel installeren overeenkomstig de lokale en nationale elektrische voorschriften.
  • Page 40 Standardit: Tämä tuote on seuraavien standardien mukainen. Radioaaltojen häirintä FCC Part 15 (Class A), EN55022 (Class A), EN61000-3-2, EN61000-3-3 Varoitus: Kotiolosuhteissa tämä laite voi aiheuttaa radioaaltojen häiröitä, missä tapauksessa laitteen käyttäjän on mahdollisesti ryhdyttävä tarpeellisiin toimenpiteisiin. Kestävyys EN55024 Sähköturvallisuus UL 1950 (UL/cUL), EN60950 (TUV), EN60825 VAROITUS Luokan 1 Lasertuote.
  • Page 41 AT-FS713FC/xx and AT-FS717FC/xx Series Installation Guide AVVERTENZE ELETTRICHE Attenzione: PERICOLO DI SCOSSE ELETTRICHE Per evitare SCOSSE ELETTRICHE non asportare il coperchio. Le componenti interne non sono riparabili dall’utente. Questa unità ha TENSIONI PERICOLOSE e va aperta solamente da un tecnico specializzato e qualificato. Per evitare ogni possibilità di SCOSSE ELETTRICHE, interrompere l’alimentazione del dispositivo prima di collegare o...
  • Page 42 Driftstemperatur: Dette produktet er konstruert for bruk i maksimum romtemperatur på 40 grader celsius. Alle Land: Produktet må installeres i samsvar med de lokale og nasjonale elektriske koder. Padrões: Este produto atende aos seguintes padrões. Emissão de interferência de radiofrequência FCC Part 15 (Class A), EN55022 (Class A), EN61000-3-2, EN61000-3-3 Aviso: Num ambiente doméstico este produto pode causar interferência na...
  • Page 43 AT-FS713FC/xx and AT-FS717FC/xx Series Installation Guide Estándares: Este producto cumple con los siguientes estándares. Emisión RFI FCC Part 15 (Class A), EN55022 (Class A), EN61000-3-2, EN61000-3-3 Advertencia: en un entorno doméstico, este producto puede causar radiointerferencias, en cuyo caso, puede requerirse del usuario que tome las medidas que sean convenientes al respecto.
  • Page 44 Tillkännagivanden Beträffande Elektricitetsrisk: RISK FÖR ELEKTRISK STÖTFör att undvika ELEKTRISK stöt, ta ej av locket. Det finns inga delar inuti som behöver underhållas. Denna apparat är under HÖGSPÄNNING och får endast öppnas av en utbildad kvalificerad tekniker. För att undvika ELEKTRISK STÖT, koppla ifrån produktens strömanslutning innan LAN- kablarna ansluts eller kopplas ur.
  • Page 45: Technical Support Fax Order

    Appendix C Technical Support Fax Order Name _________________________________________________________________ Company ______________________________________________________________ Address _______________________________________________________________ City______________________ State/Province_______________________________ Zip/Postal Code ________________ Country_______________________________ Phone______________________________ Fax ________________________________ Incident Summary Model number of Allied Telesyn product I am using ________________________ Firmware release number of Allied Telesyn product _______________________ Other network software products I am using (e.g., network managers) ______________________________________________________________________ ______________________________________________________________________...
