Allied Telesis AT-FS704 Installation Manual

10/100 fast ethernet unmanaged switch

Advertisement

Quick Links

AT-FS704
10/100 Fast Ethernet
Unmanaged Switch

Installation Guide

PN 613-10778-00 Rev. A

Advertisement

Table of Contents
loading

Summary of Contents for Allied Telesis AT-FS704

  • Page 1: Installation Guide

    AT-FS704 10/100 Fast Ethernet Unmanaged Switch Installation Guide PN 613-10778-00 Rev. A...
  • Page 2 Copyright ©1998 Allied Telesyn International, Corp. 950 Kifer Road, Sunnyvale CA 94086 USA All rights reserved. No part of this publication may be reproduced without prior written permission from Allied Telesyn International, Corp. Ethernet is a registered trademark of Xerox Corporation. All company names, logos, and product designations that are trademarks or registered trademarks are the property of their owners.
  • Page 3: Electrical Safety And Installation Requirements

    Electrical Safety and Installation Requirements STANDARDS: This product meets the following standards U.S. Federal Communications Commission RADIATED ENERGY Note: This equipment has been tested and found to comply with the limits for a Class A digital device pursuant to Part 15 of FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.
  • Page 4 Electrical Safety and Installation Requirements ELECTRICAL—TYPE CLASS 1 EQUIPMENT THIS EQUIPMENT MUST BE EARTHED. Power plug must be connected to a properly wired earth ground socket outlet. An improperly wired socket outlet could place hazardous voltages on accessible metal parts. ELECTRICAL—CORD NOTICE Use power cord, maximum 4.5 meters long, rated 6 amp minimum, 250V, made of HAR cordage molded IEC 320 connector on one end and on the other end a plug approved by the country of end...
  • Page 5 AT-FS704 Installation Guide VORSICHT Die Entlüftungsöffnungen dürfen nicht versperrt sein und müssen zum Kühlen freien Zugang zur Raumluft haben. BETRIEBSTEMPERATUR Dieses Produkt wurde für den Betrieb in einer Umgebungstemperatur von nicht mehr als 40° C entworfen. ALLE LÄNDER: Installation muß örtlichen und nationalen elektrischen Vorschriften entsprechen.
  • Page 6 Electrical Safety and Installation Requirements EISEN: Dit product voldoet aan de volgende eisen. WAARSCHUWING: Binnenshuis kan dit product radiostoring veroorzaken, in welk geval de gebruiker verplicht kan worden om gepaste maatregelen te nemen. RFI Emissie EN55022 Klasse A WAARSCHUWING: Dit product vereist beschermende kabels in overeenstemming met de limieten van Klasse A emissie.
  • Page 7 AT-FS704 Installation Guide NORMES: ce produit est conforme aux normes de suivantes : MISE EN GARDE: dans un environnement domestique, ce produit peut provoquer des interférences radioélectriques. Auquel cas, l’utilisateur devra prendre les mesures adéquates. Emission d’interférences radioélectriques EN55022 Classe A MISE EN GARDE: conformément aux limites d’émission de la Classe A, ce produit doit être utilisé...
  • Page 8 Electrical Safety and Installation Requirements STANDARDIT: Tämä tuote on seuraavien standardien mukainen. VAROITUS: Kotiolosuhteissa tämä laite voi aiheuttaa radioaaltojen häiröitä, missä tapauksessa laitteen käyttäjän on mahdollisesti ryhdyttävä tarpeellisiin toimenpiteisiin. Radioaaltojen häirintä EN55022 Luokka A VAROITUS: Tämä tuote vaatii suojatut kaabelit täyttääkseen A Luokan säteilyrajoitukset. Ellei suojattuja kaapeleita käytetä, tämä...
  • Page 9 AT-FS704 Installation Guide STANDARD: Questo prodotto è conforme ai seguenti standard. AVVERTENZA: in ambiente domestico questo prodotto potrebbe causare radio interferenza. In questo caso potrebbe richiedersi all’utente di prendere gli adeguati provvedimenti. Emissione RFI (interferenza di radiofrequenza) EN55022 Classe A AVVERTENZA: questo prodotto richiede cavi schermati per adeguarsi ai limiti di emissione per gli apparecchi di Classe A.
  • Page 10 Electrical Safety and Installation Requirements SIKKERHETSNORMER: Dette produktet tilfredsstiller følgende sikkerhetsnormer. ADVARSEL: Hvis dette produktet benyttes til privat bruk, kan produktet forårsake radioforstyrrelse. Hvis dette skjer, må brukeren ta de nødvendige forholdsregler. RFI stråling EN55022 Klasse A ADVARSEL: Det må benyttes isolerte kabler med dette produktet for å tilfredsstille Klasse A strålingsgrenser.
  • Page 11 AT-FS704 Installation Guide PADRÕES: Este produto atende aos seguintes padrões. AVISO: Num ambiente doméstico este produto pode causar interferência na radiorrecepção e, neste caso, pode ser necessário que o utente tome as medidas adequadas. Emissão de interferência de radiofrequência EN55022 Classe A AVISO: Este produto requer cabos protegidos a fim de obedecer aos limites de emissão da Classe...
  • Page 12 Electrical Safety and Installation Requirements ESTÁNDARES: Este producto cumple con los siguientes estándares. ADVERTENCIA: en un entorno doméstico, este producto puede causar radiointerferencias, en cuyo caso, puede requerirse del usuario que tome las medidas que sean convenientes al respecto. Emisión RFI EN55022 Clase A ADVERTENCIA: este producto requiere de cables armados para cumplir con los límites de emisión de Clase A.
  • Page 13 AT-FS704 Installation Guide STANDARDER: Denna produkt uppfyller följande standarder. VARNING: Denna produkt kan ge upphov till radiostörningar i hemmet, vilket kan tvinga användaren till att vidtaga erforderliga åtgärder. Radiostörning EN55022 Klass A VARNING: Skärmkabel bör användas med denna produkt för att uppfylla kraven gällande radiostörningar enligt Klass A.
  • Page 15: Table Of Contents

    Agency Compliance................... 13 100Base-TX Cable .................... 15 100Base-TX Connector Pinouts ............... 15 Straight-through Cable Crossover Cable ..........15 Technical Support Fax Order ..............17 Incident Summary .................... 17 AT-FS704 Switch Installation Guide Feedback ........19 Where To Find Us ..................21...
  • Page 17: Product Description

    POWER Figure 1 AT-FS704 Front and Rear Panels The AT-FS704 is designed for easy installation and high performance in an environment where traffic on the network and the numbers of users increase continuously; it can be installed where space is limited, and it provides immediate access to a rapidly growing network through a wide range of user- reliable functions and features, as described in the following section.
  • Page 18: Key Features

    Product Description Key Features The AT-FS704 unmanaged Fast Ethernet switch has the following features: IEEE 802.3 and 802.3u compliant. Store-and-forward at full wire speed to support rate adaptation and ensure data integrity. Auto-negotiation for any port. This allows for auto-detection of speed...
  • Page 19: Physical Description

    Figure 2 AT-FS704 Front Panel defined Rear Panel The rear panel of the AT-FS704 consists of an AC power connector, as shown in Figure 3. Supported input voltages range from 100 ~ 240 V AC at 50 ~ 60 Hz.
  • Page 20: Led Indicators

    LED indicators represents a reset of the system. The FDX/Col LED indicators blink from yellow to green. The power LED indicator will remain ON. Figure 4 shows the LED indicators on the AT-FS704 and Table 1 provides an explanation of each indicator: 100M...
  • Page 21: Power Supply

    AT-FS704 Installation Guide Power Supply The AT-FS704 can be used with AC power sources 100 - 240 V AC, 50/60 Hz. To power the unit ON, plug one end of the power cord into the AC power connector of the unit and the other end into the local power source outlet.
  • Page 23: Installation

    Chapter 2 Installation Before you Proceed Before installing the AT-FS704, make sure you read “Electrical Safety and Installation Requirements” on page iii. Verifying Package Contents Make sure that the package includes the following items: One AT-FS704 10/100 Fast Ethernet Switch One AC power cord (for the U.S., Continental Europe, and the U.K.
  • Page 24: Site Requirements

    Ensure the surface supports at least 1.2 Kg. Desktop Installation When installing the AT-FS704 on a desktop or shelf, first attach the rubber feet included with the device. Attach these cushioning feet on the bottom at each corner of the device. Allow enough ventilation space between the device and the objects around it.
  • Page 25: Wall Installation

    AT-FS704 Installation Guide Wall Installation The AT-FS704 comes with a wall mount kit. This kit includes two screws and two plastic anchors. For a proper placement on the wall, follow these installation requirements: Select a site that is free of obstructions from other equipment or devices.
  • Page 26: Pc- To-Switch Installation

    Installation PC- to-Switch Installation A PC can be connected to the AT-FS704 with a two-pair Category 5 UTP/STP RJ45 straight cable. The PC (equipped with a RJ45 10/100 Mbps jack) should be connected to any of the four ports (1X-4X). See Figure 6.
  • Page 27: Hub-To-Switch Installation

    AT-FS704 Installation Guide Hub-to-Switch Installation A hub (10/100Base-TX) can be connected to the AT-FS704 using a two-pair Category 5 UTP/STP RJ45 straight cable. Connect the hub uplink (MDI) port to any of the switch (MDI-X) ports, 1X-4X. See Figure 7.
  • Page 28: Switch-To-Switch Installation

    To PC 4 PORT ETHERNET SWITCH Figure 9 AT-FS704 Switch to Switch Connection Using the Straight or Crossover Cable Options Figure 9 demonstrates using straight or crossover cable. When using straight cable, connect the uplink (MDI) port of the switch (Switch A) to any 10 Mbps or 100 Mbps (MDI-X) port of the other switch (Switch B), or other device.
  • Page 29: Technical Specifications

    Appendix A Technical Specifications Physical Characteristics Dimensions: 232 x 142 x 43 mm Weight: 1.2 Kg Operating temperatures: 0° to 40° C Storage temperatures: -30° to 60° C Relative humidity: 5% to 95% non-condensing Number of ports: 4 x 10/100 Mbps ports Media interface exchange: MDI RJ45 shared with port 1X Agency Compliance...
  • Page 30 Technical Specifications Recommended Cables and Cable Specifications The cable between the switch and the link partner (hub, workstation) must be less than 100 m (328 ft) long. 10Base-T segments can use 22, 24 or 26-gauge TP cabling that complies with IEEE 802.3 10Base-T standard for Category 3, 4 or 5.
  • Page 31: 100Base-Tx Cable

    AT-FS704 Installation Guide 100Base-TX Cable There are various grades of voice-quality and data-quality cables available. These can appear to be similar externally, although their high-speed data transmission characteristics are radically different. The identification problem is made worse by some suppliers selling voice-quality cables as data-quality cables.
  • Page 33: Technical Support Fax Order

    Appendix B Technical Support Fax Order Name _________________________________________________________________________ Company______________________________________________________________________ Address_______________________________________________________________________ City ___________________________State/Province___________________________________ Zip/Postal Code ______________________ Country___________________________________ Phone __________________________________ Fax___________________________________ Incident Summary Model number of Allied Telesyn product I am using ___________________________________ Network software products I am using _____________________________________________ ______________________________________________________________________________ Brief summary of problem _______________________________________________________ ______________________________________________________________________________ Conditions (List the steps that led up to the problem.) ________________________________ ______________________________________________________________________________...
  • Page 35: At-Fs704 Switch Installation Guide Feedback

    Appendix C AT-FS704 Switch Installation Guide Feedback Please tell us what additional information you would like to see discussed in this guide. If there are topics you would like information on that were not covered in this guide, please photocopy this page, answer the questions and fax or mail this form back to Allied Telesyn.
  • Page 37: Where To Find Us

    Appendix D Where To Find Us For Technical Support or Service Location Phone Americas 1 (800) 428-4835 1 (918) 628-3222 United States, Canada, Mexico, Central America, South America Asia (+65) 3815-613 (+65) 3833-830 Singapore, Taiwan, Thailand, Malaysia, Indonesia, Korea, Philippines, China, India Australia (61) 2-943-5111 (61) 2-416-9438-4966...
