AT -FS700 SERIES
Unmanaged Fast Ethernet Switches
AT -FS705L-xx
5-port 10/100TX unmanaged switch
with internal power supply
AT -FS705LE-xx
5-port 10/100TX unmanaged switch
with external power supply
AT -FS708-xx
8-port 10/100TX unmanaged switch
with internal power supply
AT -FS708LE-xx
8-port 10/100TX unmanaged switch
with external power supply
AT -FS708L-xx
8-port, small form factor, 10/100TX
unmanaged desktop switch with
internal power supply
AT -FS716L-xx
16-port 10/100TX unmanaged switch
with internal power supply
AT -FS716LE-xx
16-port 10/100TX unmanaged switch
with external power supply
AT -FS724L-xx
24-port 10/100TX unmanaged switch
with internal power supply
Allied Telesyn
High Performance
Providing powerful 10/100 switching solutions
for desktop and small network environments,
the Allied Telesyn AT-FS700 series of unmanaged
switches features full auto-negotiating 10/100
ports. These ports enable the switches to
detect the speed and duplex modes of attached
devices, enabling them to automatically configure
for the best possible performance.
Flexibility
Available as 5-, 8-, 16-, or 24-port models, the
ATFS700 Series meets a multitude of power
requirements with both internal and external
power-supply options. Also, wall-, desk-, and
rack-mounting options give users ultimate
flexibility in selecting the model that meets
their physical deployment requirements.
Simplified Installation
Fully auto-configuring AT-FS700 Series switches
require minimal set-up by the user. Auto-sensing
ports enable seamless and simple connectivity
between existing 10Mbps Ethernet and 100Mbps
Fast Ethernet UTP devices—and all units can
be installed in minutes. Every AT-FS700 Series
models is equipped with MDI/MDIX ports for
simple connection to other hubs and switches.
Finally, easy to read front panel LEDs show ongoing
switch status and simplify troubleshooting.
Quality & Reliability
Allied Telesyn is a worldwide leader in unmanaged
Ethernet switches. Shipping more than 250,000
unmanaged switches each year, Allied Telesyn
offers proven reliability and industry recognized
quality. Every unmanaged switch is backed with
a lifetime limited warranty.
Key Features
• 5 to 24 10/100TX ports
• Wirespeed technology
• Non-blocking architecture
• Auto-negotiation ports
• Auto MDI/MDIX ports
• Transparent to VLAN packets
• Half- & full-duplex flow control
• External or internal power
supply option
• Sturdy metal case
• Retainer clip to secure power
connection*
• Limited lifetime warranty
* FS708, FS708L, and FS716L
