OVEN AND ACCESSORIES

1 Control Panel
2 Oven Lamp
3 Door opening button
4 Waveguide cover
5 Coupling
6 Oven cavity
7 Door seals and sealing
surfaces
8 Door latches
9 Ventilation openings
10 Outer cabinet
11 Power cord
ACCESSORIES:
Check to make sure the following accessories
are provided:
12 Turntable 13 Turntable support 14 Coupling
Place the turntable support in the centre of the oven floor so that it can
freely rotate around the coupling.
Place the turntable onto the turntable support so that it locates firmly into
the coupling.
To avoid turntable damage, ensure dishes or containers are lifted clear
of the turntable rim when removing them from the oven.
NOTES:
• When you order accessories, please mention two items: part name
and model name to your dealer or SHARP authorised service agent.
• Always operate the oven with the turntable and support fitted
correctly. This promotes thorough even cooking. A badly fitted
turntable may rattle, may not rotate properly and damage the oven.
• The turntable rotates clockwise or counter clockwise. The rotary
direction may change each time you start the oven. This does not
affect cooking performance.
08:49 Page 2
7
6
5
8
11
2
2
3
4
ROAST BEEF / LAMB
ROAST PORK ROAST POULTRY
CHICKEN PORTIONS SOUP
Kg Lb Pcs
Time
DOWN UP LESS MORE
AUTO START
KITCHEN
Kg/Lb
TIMER
CLOCK
STOP START
POWER
LEVEL CLEAR AUTO MINUTE
R-353
1
9
10
12
13
14
