OPCODE STUDIO 4 Instruction page 91

striping tutorial 65
striping w/networks 64
syncing tutorial 66
user bits 57, 64
with Vision 67
SMPTE In jack 9
SMPTE Indicator 8
SMPTE Out jack 9
SMPTE Reader command 57
SMPTE Reader window 57
SMPTE Reader with networks 59
Standard interface
networking with Studio 4 16, 75–77
State
definition 53
do nothing state 54
opening 54
saving 53
Stripe SMPTE command 61
Stripe SMPTE window 61
Stripe SMPTE with networks 64
Studio Setup document
creating 20
Studio 4 icons 22
updating 21
Studio 3
networking with Studio 4 16, 75–78
Studio 4
definition 3
front panel 7
icons 22
installing 11
multiple 32
packing list 4
rear panel 8
Studio 4 menu 31
Display ROM Version command 32
Jam Sync option 63
MIDI Routing, Channelizing and Muting
command 39
Multiple Computers option 13
Network Routing command 33
Studio 4 Manual
Open command 54
Save As command 54
Save command 53
SMPTE Reader command 57
Stripe SMPTE command 61
with networks 32
Studio 4 state
definition 53
do nothing state 54
opening 54
saving 53
Switch
1-8/9-16 8
1MHz/Fast 7
power 8
thru (A & B) 8
T
Technical support 4
Thru ports 9
Thru switches 8
Timecode
displaying 57
Network Routing window 35
Timecode routing 48
U
Update Setup dialog box 21
User bits 64
displaying 57
V
Vision
using with SMPTE 67
Index
83
