SMPTE, Vision and the Studio 4
The following discusses using the
Studio 4 with Vision. The information is
also applicable to working with Studio
Vision.
Vision uses MIDI Time Code for synchro-
nization, so...
Choose Stripe SMPTE from the
Studio 4 menu and choose MIDI
Time Code from the MIDI Format
pop-up menu.
Figure 10.9: Choose MIDI Format
Disable Jam Sync in the Studio 4
menu.
Choose Options>Receive Sync
Mode>MIDI Time Code in Vision.
Choose Options>Receive Sync
Device>Studio 4 in Vision.
Select the desired playback
sequence, its Sync and its Offset.
Click Play in VisionÕs Control
window. The play button will flash
while Vision waits for sync.
Hit Play on your tape recorder and
Vision will start playing back in sync
with the tape.
Studio 4 Manual
CHAPTER 10: Stripe SMPTE Window
Use a similar procedure for recording
tracks into Vision while synchronized to
tape. For more information concerning
Vision's various sync modes, see your
Vision manual.
