PART 2: Using The Studio 4
Display ROM Version...
Choose this command to display the ver-
sion numbers of your Studio 4 ROM. You
should know your ROM version if you call
Opcode Technical Support about your
Studio 4.
Choosing Between Multiple
Studio 4's
Any time the current Studio Setup docu-
ment contains more than one Studio 4,
you'll see a listing of them at the bottom of
the Studio 4 menu.
To select (check) a Studio 4, simply pull
down the menu and release the mouse
over the desired Studio 4.
The SMPTE Reader and Stripe SMPTE
windows work with the selected Studio 4.
You must select a Studio 4 before opening
either the SMPTE Reader or Stripe
SMPTE windows. The SMPTE Reader
window is discussed in Chapter 9. The
Stripe SMPTE window is discussed in
Chapter 10.
Choose any Studio 4 on a modem port to
open either a Network Routing window or
a Routing, Channelizing and Muting
window for the modem port. Similarly,
choose any Studio 4 on a printer port to
open either a Network Routing window or
a Routing, Channelizing and Muting
window for the printer port. The Network
Routing window is discussed in
Chapter 6. The Routing, Channelizing and
Muting window is discussed in Chapter 7.
32
Using the Studio 4 Menu with a
MIDI Time Piece
If you network a MIDI Time Piece with a
Studio 4, the MTP appears as a Studio 4 in
the Studio Setup document and is labeled
"MTP as S4". Everything in the Studio 4
menu works with the networked MTP
except Stripe SMPTE, Jam Sync and
Display ROM Version. You can open
the SMPTE Reader window for a MIDI
Time Piece that's networked to a Studio 4
and it'll work except you can't change the
MIDI synchronization format.
