Cypress DataBender CVX-1300 Operation Manual page 23

Wiring Diagram #7 Wiegand to Strobed
Reader powered by external supply (8 to 16 VDC)
Data0
Card
Data1
Reader
Ground
Data0
Card
Data1
Reader
Ground
D0/Clock In
D1/Data In
Ground
Data Bender®
+8 to +16 VDC In
Reader powered by 5 Volt Supply
D0/Clock In
D1/Data In
Ground
Data Bender®
+8 to +16 VDC In
Clock Out
Data Out
Ground
Clock Out
Data Out
+5VDC Out
Ground
Clock
Data
Access
Ground
Control
Panel
(-)
DC
Power
(+)
Supply
Clock
Data
Access
Ground
Control
Panel
(-)
DC
Power
(+)
Supply
