- Page 1 Multisystem Color Corrector Model CCR-8 Instruction Manual...
- Page 3 Introduction The Cypress Color Corrector, Model CCR-8, has been designed for the professional videographer who wants to adjust a video signal to achieve the best possible viewing of video tapes.This allows you to enhance bright or dark videos and adjust for color balance problems on your home movies.
-
Page 4: Typical Hook-Up
The diagram below shows how to connect between either a camcorder or VCR and a recording VCR. Step 1: Plug the 7.5 VDC plug into the CCR-8 and the adapter into a standard AC outlet. Step 2: Connect the video outputs of the playback VCR or camcorder to one of the four Video inputs on the CCR-8 . -
Page 5: Operation
Standby / Power Select: When power adapter is pluged in, the CCR-8 enters into standby mode, the Standby LED illuminates.The unit can be further powered on by pressing the power button either on the remote or on the front panel. - Page 6 MENU/ - / +/ / buttons: [ Main Menu ] .Press MENU button to enter Main Menu: Video Adjustment Output System OSD Display :select - +:enter MENU:exit .Press or button to select the item you want to adjust. .Press - or + button to enter the selected item. .Press MENU to exit menu.
- Page 7 .Press orbutton to select your desired output system. Press - or + button to enter the selected item. .Press MENU to return to Main Menu. .CCR-8 doesn't conduct field conversion (50Hz/60Hz conversion). .The table shows video color system conversion between the input and output. Select item...
-
Page 8: Remote Control
Remote control ▲ ▼ DISPLAY POWER MENU/EXIT INPUTS CR-18 1. Power : Press the button to power on the unit 2. MENU/EXIT : Press to enter main menu page or to exit from the selected parameter ▲ ▼ Press to move up / down the high-light bar to your desired adjust parameter 4. -
Page 9: Technical Specifications
Technical Specifications Video Inputs : Composite Video (RCA style phono jack) 75 ohm, unbalanced, 1 Vp-p S-Video (4 pin mini DIN) Y: 1 Vp-p,75 ohms,unbalanced C: 0.286 Vp-p, burst signal, 75 ohms Outputs : Composite Video (RCA style phono jack) 75 ohm, unbalanced, 1 Vp-p S-Video (4 pin mini DIN) Y: 1 Vp-p,75 ohms,unbalanced...
