Cypress DataBender CVX-1300 Operation Manual page 18

Wiring Diagram #3 Wiegand to Wiegand
Reader powered by external supply (8 to 16 VDC)
Data0
Card
Data1
Reader
Ground
Data0
Card
Data1
Reader
Ground
D0 Output
D0 Input
D1 Output
D1 Input
Ground
Data Bender®
+8 to +16 VDC In
Reader powered by 5 Volt Supply
D0 Output
D0 Input
D1 Output
D1 Input
Ground
+5 VDC Out
Data Bender®
Ground
+8 to +16 VDC In
Ground
Data 0
Data 1
Ground
Data 0
Data 1
Access
Ground
Control
Panel
(-)
DC
Power
(+)
Supply
Access
Control
Panel
(-)
DC
Power
(+)
Supply
