- Page 1 CVX-OPTW Wiegand Splitter Operations Manual CVX-OPTW_MAN_081216...
- Page 2 (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Cypress Computer Systems, Inc. ⌖ Lapeer, MI 48446 ⌖ www.cypressintegration.com © 2015 Cypress Computer Systems Inc.
- Page 3 The CVX-OPTW allows multiple readers and panels to be connected together. The CVX-OPTW also allows systems with different voltage levels to be electrically connected together. The CVX-OPTW may be cascaded to connect additional readers or panels to be connected. +5 VDC...
- Page 4 Data 1 OUT Ground Previous versions of the CVX-OPTW had internal pullup resistors connected to the output ports. These pullup resistors were wired to the +5VDC supply. This newer version provides the option of connecting the pullup resistors in order to allow connection as a true open collector output.
- Page 5 5VDC ONLY Card Reader Access Panel 1 2 readers connected to 1 panel Card Reader 5VDC ONLY Card Reader Access Panel 1 1 Reader connected to 2 panels Access Panel 2...
- Page 6 1 Reader connected to multiple panels 5VDC ONLY (typical) V+ GND Card Reader Access Panel 1 Access Panel 2 Access Panel 3 Access Panel 4...
