18) IN 5 SWITCH
ON/OFF. This is the level of the digital input#5 CNA#20 in AmpSaab
connector [CNA#19 in AmpSeal connector]:
-
-
19) BELLY SWITCH
ON/OFF. This is the level of the digital input CNA#33 in AmpSaab connector
[CNA#7 in AmpSeal connector] ( belly button):
-
-
20) IN 7 SWITCH
ON/OFF. This is the level of the digital input#7 CNA#34 in AmpSaab
connector [CNA#35 in AmpSeal connector] :
-
-
21) IN 8 SWITCH
Only for AmpSaab version. ON/OFF. This is the level of the digital input#8
CNA#35 in AmpSaab connector:
-
-
22) H&S CUTBACK
ON/OFF. This is the level of the digital input CNA#6 in AmpSaab connector
[CNA#29 in AmpSeal connector] for the Hard & Soft request. With the H&S
service is possible to turn the truck moving (at reduced speed) only by acting
the H&S switch, and the accelerator, without to let down the tiller :
-
-
23) LIFTING SWITCH
ON/OFF. This is the level of the digital input CNA#36 (in AmpSaab
connector, CNA#17 in AmpSeal connector) for the lifting request:
-
-
24) LIFTING CUTOUT
Page - 50/86
ON +VB = When it is closed to a battery (key) voltage, the Backward
Travel demand is Active.
OFF GND = When it is not connected to a battery (key) voltage (or it is
connected to GND), the Backward Travel demand is not active.
ON +VB = When it is closed to a battery (key) voltage the digital input#5
request is active.
OFF GND = When it is not closed to a battery (key) voltage (or
connected to GND) the digital input#5 request is not active.
ON +VB = When it is closed to a battery (key) voltage, the request of the
Belly (to stop the movement) is active.
OFF GND= When it is not connected to a battery (key) voltage (or it is
connected to GND), the Belly request is not active.
ON +VB = When it is closed to a battery (key) voltage the voltage the
digital input#7 request is active.
OFF GND = When it is not closed to a battery (key) voltage (or
connected to GND) the voltage the digital input#7 request is not active.
ON +VB = When it is closed to a battery (key) voltage the digital input#8
is active.
OFF GND = When it is not closed to a battery (key) voltage (or it is
connected to GND) the digital input#8 is not active.
ON +VB = When it is closed to a battery (key) voltage, the H&S request
is Active.
OFF GND = When it is not connected to a battery (key) voltage (or it is
connected to GND), the H&S request is not active.
ON +VB = When is closed to a battery (key) voltage, the Lifting request is
Active.
OFF GND = When is not connected to a battery (key) voltage (or it is
connected to GND), the Lifting request is not active.
