- Page 1 Vehicle Tracker User Manual V7.1 VT300...
-
Page 2: Table Of Contents
Contents 1. Product Overview ......................... - 3 - 2. For Your Safety ........................- 3 - 3 VT300 Characteristics ......................- 4 - 4. Getting Started ........................- 4 - 4.1 Hardware and Accessories ..................... - 4 - 4.2 View ........................... - 5 - 4.3 Functional Parts ...................... -
Page 3: Product Overview
VT300 is a GPS/GSM/GPRS tracking device specially developed and designed for vehicle real-time tracking and fleet management. With superior GPS and GPRS modules, VT300 has good sensitivity and stable performance. It can get accurate GPS fix even in remote places. -
Page 4: Vt300 Characteristics
1 LED light to show working status. Button One SOS button Interface One input and one output 4. Getting Started This section will describe how to set up your VT300. 4.1 Hardware and Accessories VT300 is supplied in a box which includes: - 4 -... -
Page 5: View
Power On/Off Button To turn on/off VT300. Note: The switch is on off side as factory default. When the wires are plugged in, VT300 will be switched on automatically as the two yellow cables (SW1 and SW2) are connected together. SOS Button SOS button is connected with the wires. -
Page 6: Connecting And Installation
4.5V. 4.4 Connecting and Installation Read this manual before using your VT300. Check to make sure all parts are included in the packaging box. 4.4.1 Ensure that your VT300 has a working SIM card installed. - Check that the SIM card has not run out of credit (test the SIM card in a phone to make sure it can send and receive SMS). -
Page 7: Change Password
Check that the Red LED (Battery) is flashing 1 second on and 2 seconds off. Make a missed phone call the VT300 using a mobile phone to check if the call can go through. The VT300 should reply with an SMS indicating longitude, latitude, speed and date. -
Page 8: Track
7. Track 7.1 Track by SMS - Track on Demand - Reply with longitude, latitude, speed and date Command: W******,000 Description: To get the current location of the tracker, send this command as an SMS or make a telephone call directly to the tracker. After doing so, the device will report its longitude and latitude by SMS with the format as follows: Latitude = 22 32 36.63N Longitude = 114 04 57.37E, Speed = 2.6854Km/h, 2008-12-24,01:50 Example:... -
Page 9: Google Earth And Google Maps
W000000,002,030 The tracker will send location data back to your mobile phone every 30 minutes. 7.4 Google Earth and Google Maps Download Google Earth from http://earth.google.com/. Start Google Earth (For more information about Google Earth please refer to http://earth.google.com/ or go to http://maps.google.com). -
Page 10: Track By Gprs (Meiligao Protocol) Between Server And Tracker
7.6 Track by GPRS (Meiligao Protocol) between Server and Tracker 7.6.1 Set Tracker’s GPRS ID Command: W******,010,ID Description: Sets a digital GPRS ID for the tracker. Note: GPRS ID must not be over 14 digits. Example: W000000,010,00001 7.6.2 Set APN Command: W******,011,APN,Username,Password Description: Set APN details for the tracker Note:... -
Page 11: Set Gprs Interval
After above authorization is completed, and the SOS is pressed, an SOS SMS - “SOS Alarm” will be sent to the preauthorized phone number. Then a message with longitude and latitude will follow. (Note: An SOS button is already connected to VT300 in standard packing) - 11 -... -
Page 12: Speeding Alarm
9. Speeding Alarm Command: W******,005,XX Description: Turn on speeding alarm. When the tracker speeds higher than the preset value, it will send an SMS to the phone number for SOS. Note: XX is the preset value of speed and in 2 digits. =00 , to turn off this function;... -
Page 13: Track By Distance
Longitude is dd.dddddd, „0‟ is needed to be stuffed if no value available. „-‟ should be added for west. 3. Radii: [1, 4294967295] meter(s), suggested to be set above 100 meters, if set above 8, it is corresponding radii. 4. If In and Out are 0, corresponding function is invalid. If In and Out are 1, valid. 5. -
Page 14: Output Control (Immediate)
F=1, to open the output (low voltage). Example: W000000,120,1 W000000,220,1 Once the relay is properly installed, send this command to VT300. When its speed reaches at 10km/h or 20km/h, it will stop the engine. 13. Heading Change Report Command: W******,036,degree Description When the heading direction of the tracker changes over the preset degree, a message with location data will be sent back to the server by GPRS. -
Page 15: Get Imei
data=0, to turn off this function; data=1~65535, set interval for heartbeat. Example: W000000,015,10 In this example, the tracker will send heartbeat every 10 minutes. 15. Get IMEI Command: W******,601 Description: Get IMEI of the tracker. IMEI is 15 digits Example: W000000,601 16. -
Page 16: Copyright And Disclaimer
Please refer to Meitrack Parameter Editor for more information. 19. Copyright and Disclaimer © Shenzhen Meiligao Electronics Co., Ltd. All rights reserved. The information contained herein may be changed at any time without prior notification. This manual nor any parts thereof may not be reproduced for any purpose whatsoever without written consent of Meiligao, or transmitted in any form either electronically or mechanically, including photocopying and recording. - Page 17 tracker. After doing so, the device will report its longitude and latitude by SMS with format as follows: Latitude = 22 32 36.63N Longitude = 114 04 57.37E, Speed = 2.6854Km/h, 2008-12-24,01:50 Track on Demand W******,100 W000000,100 -Google Link Remarks: Send this command to the tracker and you will receive an SMS with a http link. Click on the link then the location will be shown directly on your mobile phone using Google Maps.
- Page 18 Note: 1. X is the parameters which includes: latitude, longitude, radii, in, out. 2. Latitude and longitude should be in ASCII format as follows: Latitude is ddd.dddddd, „0‟ is needed to be stuffed if no value available. „-‟ should be added for south. Longitude is dd.dddddd, „0‟...
- Page 19 Presetting by SMS for GPRS tracking (Ensure that your SIM card supports GPRS connection prior to setting) Set Tracker’s GPRS ID W******,010,ID W000000,010,00001 Remarks: to set a digital GPRS ID for the tracker. GPRS ID must not over 14 digits. Set APN W******,011,APN,Username, W000000,011,CMNET,Meiligao,6688...
- Page 20 Remarks: Send this command to set sensitivity of tremble sensor. Note: XX=[1,255], it will be more sensitive if XX is smaller Default value is 30. Example: W000000,035,30 Heading Change Report W******,036,degree W000000,036,90 Remarks: when the heading direction of the tracker changes over the preset degree, a message with location data will be sent back to the server by GPRS.
-
Page 21: Annex 2. Troubleshooting
T=0, to turn off this function; T=[-32768,32767] to set time difference in minute to GMT. For those ahead of GMT, just input the time difference in minutes directly. For example, GMT+8, W000000,032,480 ( 8 hours is 480 minutes). „-„is required for those behind GMT. For example, W000000,032,-120. Set SMS Header W******,033,P,Char W000000,033,1,help... - Page 22 seconds off) GSM Network is slow Some GSM networks slow down during peak time or when they have equipment problems Unit is sleeping or in power down mode Cancel sleeping mode or power down Wrong password in your SMS or wrong SMS Write correct password or SMS format format The SIM has run out of credit...
- Page 23 GPRS function of VT300 is turned off Turn on GPRS function of VT300 Incorrect IP address or PORT Get the right IP address and PORT and reset to VT300 GSM signal is weak Move the unit to a location with good GSM reception...
-
Page 24: Contacts
GPRS function of VT300 is turned off Turn on GPRS function of VT300 Incorrect IP address or PORT Get the right IP address and PORT and reset to VT300 GSM signal is weak Move the unit to a location with good GSM reception...
