MEITRACK® Vehicle GPS Tracker
Copyright © 2014 Meitrack Group All rights reserved.
File Name:
MEITRACK MVT800 User Guide
Project:
MVT800
Sub Project:

User Guide

Revision:
V1.8
User Guide
MVT800
Creator:
Creation Date:
Update Date:
Page:
Confidential:
External Documentation
Meitrack
2013-03-03
2014-02-26
1 of 25
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MVT800 and is the answer not in the manual?

Questions and answers

Related Manuals for MeiTrack MVT800

Summary of Contents for MeiTrack MVT800

  • Page 1: User Guide

    MEITRACK MVT800 User Guide Creator: Meitrack Project: MVT800 Creation Date: 2013-03-03 Update Date: 2014-02-26 Sub Project: User Guide Page: 1 of 25 Revision: V1.8 Confidential: External Documentation MEITRACK® Vehicle GPS Tracker User Guide MVT800 Copyright © 2014 Meitrack Group All rights reserved.

  • Page 2: Table Of Contents

    7.2.7 Remote Control Stop Engine ......................24 7.2.8 Buzzer Alarm (Optional) ........................24 7.2.9 Detection Port of Temperature and Fuel --- Meitrack Protocol Only (Optional) ......25 7.2.10 Port of Microphone and Speaker (Optional) ................. 25 7.3 Mount the MVT800 Unit ..........................25...

  • Page 3: Copyright And Disclaimer

    Meiligao (MEITRACK), or transmitted in any form, either electronically or mechanically, including photocopying and recording. In no event shall Meiligao (MEITRACK) be liable for direct, indirect, special, incidental, or consequential damages (including but not limited to economic loss, personal injury, and loss of asset and property) arising out of the use or inability or illegality to use the product or documentation.

  • Page 4: Specifications

    4Digital Input(1 SOS, 1 Positive,1 Door Trigger, 1 ACC Detection) 1 Pulse Speed Detection 2 Output(1 Buzzer Alarm,1 Remote Engine Cut) 1 Analog Input 1 Input for Digital Temperature Sensor 1 USB232 Interface 1Wireless Remote Control (433Mhz) Copyright © 2014 Meitrack Group All rights reserved.

  • Page 5: Mvt800 And Accessories

    MVT800 with Battery GPS Antenna GSM Antenna I/O Cable Power Extension Cord SOS Button USB Data Cable Optional Accessories: Wireless Buzzer Alarm Microphone Speaker Remote Control Fuel Sensor Temperature RF Antenna Sensor Copyright © 2014 Meitrack Group All rights reserved.

  • Page 6: View

    Check the SIM Lock code feature is off; If MVT800 required to send SMS to a function phone number, make sure the Caller ID is not block. Before installing the SIM card, make sure the MVT800 is power off.

  • Page 7: Led Indications

    For the first time use of USB-to-serial cable, it is required to install the PL2303 Driver Connect the USB Data Cable between MVT800 and PC. Meitrack Manager will automatically detect port and model, and enter into the main interface as follow: Copyright © 2014 Meitrack Group All rights reserved.
  • Page 8 File Name: MEITRACK MVT800 User Guide Creator: Meitrack Project: MVT800 Creation Date: 2013-03-03 Update Date: 2014-02-26 Sub Project: User Guide Page: 8 of 25 Revision: V1.8 Confidential: External Documentation Copyright © 2014 Meitrack Group All rights reserved.

  • Page 9: Set Authorized Phone Number

    6.3.1 Set Authorized Phone Number Select Column 4 Authorize: to set authorized phone number, event, etc. Please refer to the MEITRACK Manager User Guide for more detailed information regarding configuration and functions. Copyright © 2014 Meitrack Group All rights reserved.

  • Page 10: Set Gprs/Sms Tracking

    Please refer to the MEITRACK Manager User Guide for more detailed information regarding configuration and functions. Note: Meitrack Manager software can be found in the enclosed CD. The Language will be chosen automatically according to the user operating system or press Ctrl + L to change the language.

  • Page 11: Protocol Selection

    Notice: please don’t switch the protocol to Meiligao if necessary, or some functions may not work via the same command. MVT800 is compatible with both Meitrack and Meiligao Protocol (Default: Meitrack Protocol). Please set through Meitrack Manager. Steps: Connect MVT800 with Personal Computer, click Meitrack Manager.exe, enter the main interface to configure device and click Switch to Meiligao Protocol to change the default Meitrack Protocol to Meiligao Protocol.
  • Page 12 &q=22.540103,114.0 Longitude: 114.057235 location. 82329 & ie=UTF8&z=1 6&iwloc=addr&om=1 If your mobile cannot visit HTTP websites, input the latitude and longitude into Google Maps as the following picture shows to get the position: Copyright © 2014 Meitrack Group All rights reserved.

  • Page 13: Set Function Phone Numbers

    Battery Alarm, Open the Vehicle’s Door or Start the Vehicle without permission. Send command “0000, A71” to delete all function phone numbers. When the SOS button is pressed, MVT800 will make a call to the function phone number 1, 2 and 3. It will stop calling when one number answers.

  • Page 14: Arming/Disarming

    SMS Get: IMEI,B21,OK Note: Status=1 Arming, Status=0 Disarming. While in Armed status, and as been triggered by open door or engine starts; MVT800 will call or send SMS report to the function phone number. In the status of Disarm, all security alarms will be OFF.

  • Page 15: Meiligao Protocol Series

    6.6 Meiligao Protocol Series 6.6.1 Real-time Tracking by Mobile Phone Method I: Make a call to MVT800 and it will report with one SMS. Latitude = 22 32 36.63N Longitude = 114 04 57.37E, Speed = 2.6854Km/h, 2008-12-24,01:50 Location Online Checking: Visit http://maps.google.com...

  • Page 16: Set Function Phone Numbers

    1. Calibrate Automatically: GPS Speed will be calibrated automatically by transfer coefficient 1) Vehicle has been driving for 60s by the speed beyond 60km/h sequentially. 2) MVT800 has recorded the pulse numbers of sensor in 60s. 3) No sound prompt 4) It won’t be calibrated if there is no pulse.

  • Page 17: Rf Match Wireless Remote Control And Vehicle (Optional)

    Get: 0000,B23,OK 2) After the Vehicle drives at the speed of 40km/h, press SOS for 2s, MVT800 starts to count the numbers of pulse; after calibrating successfully, the buzzer will make 2 short sounds and 2 long sounds, and the green light recover to the normal status.

  • Page 18: Gps Tracking System

    Note: for more detail information Arming Status, please refer to 6.5.3 Arming/Disarming. 6.8 GPS Tracking System Steps: Configure Parameters -Log in Meitrack Family GPS Tracking System MS02 (www.trackingmate.com) - Add Devices 1. There 2 methods to configure: Configure by SMS: Send SMS command (0000,A21,1,IP,Port,APN,APN username,APN password) and (0000,A12,6,0) to MVT800.
  • Page 19 3. Enter the map and click Manage -Admin 4. Select Users and add the new device. 5. Get IMEI from serial port and register via IMEI (The IMEI is 011691003108431 for example) Copyright © 2014 Meitrack Group All rights reserved.

  • Page 20: Installation

    The covert and GPS antenna are directional, make sure they are facing up and lying as flat as possible. Secure them in place with glue or zip ties. Note: Do not shield or cover the GPS antenna with any objects containing metal. Copyright © 2014 Meitrack Group All rights reserved.

  • Page 21: Install I/O Cable

    Ground Wire: Black The interface should match the temperature sensor. (Only for USB Cable: Green Meitrack Protocol) Microphone and Green and Red Green is speaker Speaker Red is microphone Remote Control Black Antenna Copyright © 2014 Meitrack Group All rights reserved.

  • Page 22: I/O Photos

    Remote Control Antenna Fuel Detection Digital Input/ Output Port Microphone and Speaker Port Power Port USB 232 Port 7.2.3 Power Cable/Ground Wire Connect GND (-Black) and Power (+Red) wires to the battery of vehicle. Copyright © 2014 Meitrack Group All rights reserved.

  • Page 23: The Detection Port Of High Level And Low Level Configuration

    Page: 23 of 25 Revision: V1.8 Confidential: External Documentation 7.2.4 The Detection Port of High Level and Low Level Configuration 7.2.5 ACC and Door Detection 7.2.6 Signal of Vehicle Speed Sensor Detection Copyright © 2014 Meitrack Group All rights reserved.

  • Page 24: Remote Control Stop Engine

    Project: MVT800 Creation Date: 2013-03-03 Update Date: 2014-02-26 Sub Project: User Guide Page: 24 of 25 Revision: V1.8 Confidential: External Documentation 7.2.7 Remote Control Stop Engine 7.2.8 Buzzer Alarm (Optional) Buzzer Output Copyright © 2014 Meitrack Group All rights reserved.

  • Page 25: Detection Port Of Temperature And Fuel

    7.2.10 Port of Microphone and Speaker (Optional) 7.3 Mount the MVT800 Unit If mounting required, there are 4 screw holes on the MVT800, 2 along either side that act as fixing points to the vehicle. Please do not hesitate to email us at info@meitrack.com...
