SPECIFICATIONS

Dimensions
• L: 4.5 inches
• W: 4.5 inches
• H: 2.25 inches (including knobs)
Weight
• 1.00 lbs
Power
• 140mA @ 9V DC (max 180mA with Hot
Hand Wireless Adapter)
• Negative tip power jack

TROUBLESHOOTING

Noise:
Power Source
Near noise source
Other equipment
Bad cables
Hot Hand doesn't work:
Low power
Not calibrated properly
Not connected properly
22 | Specifications
Ensure that the proper power supply is being used.
Move pedal away from power supplies and other equipment.
Remove other effects from signal chain, see if noise persists.
Swap out audio cables.
Ensure that the proper power supply is being used.
Calibrate the Hot Hand — see page 20.
Check Hot Hand connections.
Audio Performance
• Maximum input level: 2.0 Vrms (+6 dBV)
• Input impedance: 1 MOhm
• Output impedance: 1 kOhm
• 115dB DNR audio path
• 24-bit audio conversion
• 56-bit digital data path
• Universal Bypass™ (buffered or relay-
based true bypass)
