Source Audio Soundblox 2 User Manual page 8

DRIVE (B)
The DRIVE knob adjusts the amount of gain applied to the signal. Dial
down the drive for a cleaner, more articulate tone and crank it up for
over-the-top doses of distortion.
VOICE (C)
The VOICE knob adjusts a midrange control located within the distortion
section of processing. This knob has a very different impact on the overall
character of the distortion than a simple EQ adjustment. Turn the knob
to the left for a warmer, cleaner tone and to the right for a thicker, more
cutting drive.
DRIVE
B
NOISE
GATE
C
8 | Controls: Knobs
TS9000
CRUNCH
TUBE
POWER
STAGE
SMOOTH
TUBE
LOW
(EXP)
TUBE DRIVE
MED
(MIDI)
HIGH
(HH)
1
VOICE
BIG PI
EL
RATON
FUZZ
FAÇADE
BENDER
METAL
OCTAVE FUZZ
GATED
FUZZ
CUT BOOST
TONE
OUTPUT
TREBLE
MID
BASS
TONE
SHAPE
(HOLD)
FLAT
2
D
F
E
