22 Installing the VoIP Loudspeaker Amplifier
Note
10. Repeat steps
Web Page Item
System Configuration
Bootname
Kernel
Application
CyberData Corporation
VoIP Loudspeaker Amplifier
7. Enter the IP address of your TFTP server into the TFTP Server IP parameter field.
8. Enter the firmware filename of the file to be uploaded into the New Filename parameter field.
For example, kernel filename "201-image-spk-sip.bin".
9. Click Upload File.
This starts the upload process. Once the speaker has uploaded the file, the Uploading
Firmware countdown page appears, indicating that the firmware is being written to flash.
The speaker will automatically reboot when the upload is complete. When the countdown
finishes, the Firmware Upgrade page will refresh. The uploaded firmware filename should
be displayed in the system configuration (indicating successful upload and reboot).
8 and 9 if you are uploading the Kernel and Application files.
For example, Application filename "201-romdisk-spk-sip.img".
Table 2-12 shows the web page items on the Firmware Upgrade page.
Figure 2-13. Firmware Upgrade Page
Table 2-12. Firmware Upgrade Parameters
Description
Shows the current configuration.
Shows the current boot loader filename.
Shows the current kernel filename for partition 1 and 2.
Shows the current application filename for partition 1
and 2.
