3C905CX-TX-M and 3C905C-TX-M NIC Specifications
Hardware
Bus interface
PCI master
Dimensions
Power requirements
Network Interface
10 Mbps Ethernet 10BASE-T
100 Mbps Ethernet
100BASE-TX
Environment
Operating temperature
Storage temperature
Operating humidity
Storage humidity
Altitude
(continued)
Specifications and
Cabling Requirements
This appendix lists the specifications, standards conformance, cable requirements, and
connector pin assignments for the EtherLink PCI NICs.
PCI Local Bus Specification, Revision 2.2
32-bit bus
Supports bus master scatter-gather DMAs.
3C905CX-TX-M:
Height: 2.00 in (5.08 cm)
Length: 4.75 in (12.07 cm)
3C905C-TX-M:
Height: 3.00 in (7.62 cm)
Length: 5.85 in (14.86 cm)
+5 V ±5% @ 375 mA maximum
+3.3 V ± 5% @ 375 mA maximum
+3.3 V @ 20mA maximum in sleep state with RWU disabled
+3.3 V Aux for RWU supplied over PCI 2.2-compliant PCI bus
Ethernet IEEE 802.3 industry standard for a 10 Mbps baseband CSMA/CD local area network
Ethernet IEEE 802.3u industry standard for a 100 Mbps baseband CSMA/CD local area network
32˚ to 158˚ F (0˚ to 70˚ C)
–22˚ to 194˚ F (–30˚ to 90˚ C)
10 to 90% noncondensing
10 to 90% noncondensing
–984 ft to 9,840 ft (–300 to 3,000 m)
51
