5 On the General screen, select the check box next to Show Icon in System Tray.
6 Close the 3Com NIC Diagnostic program.
The NIC icon appears in the Windows system tray.
When you double-click the icon, the 3Com NIC Diagnostics program starts.

Displaying Network Statistics

When you drag the mouse pointer over the icon (but do not double-click the icon) a
network statistics box appears, displaying the following information:
Frames Sent and Received—A count of the number of frames (packets) sent and
I
received through the NIC since the last time statistics were reset.
Link Speed—The speed (10 Mbps or 100 Mbps) at which the NIC is connected to
I
the network.
The information is updated each time you move your mouse pointer over the 3Com icon.
Using the 3Com Icon in the Windows System Tray
49
